6.2

Error Message Shown in the "Status Window"

When measurement parameters have some mismatch or your instrument has some adjustment error, these
error messages are indicated in the "Status Window".
This table shows error message meanings and how to operate. Please read the message and refer to operate.
If no improvement is obtained in spite of this operation, your instrument may be damaged. Please contact
Shimadzu branch.
Error Message
No Background spectrum!
Measurement aborted.
No AIM device on
Option Detector is not mounted
Parameter check Error.
There is some mismatch in the
measurement parameters. Confirm the
measurement parameters.
Diagnostic Power measurement failed
Could not retrieve diagnostic power results.
Piezo voltage is out of range.
Piezo voltage can not be obtained.
Not enough memory available! Out of
memory
Failure of mirror drive in the interferometer.
Moving Mirror Error X
Invalid QC counter
QC Timeout Error

6.2 Error Message Shown in the "Status Window"

Meanings and Operation
There is no background data stored which matches the
sample measurement (%T or Abs).
When you change parameters such as "Resolution",
background data must be measured then sample
measurement becomes available.
When mapping measurement, AIM microscope is not
connected or is just operating other task. Confirm Mapping
measurement is finished then operate again.
When Option detector is not mounted and "Option1" detector
is selected. Confirm the measurement parameters.
There is some mismatch in the measurement parameters.
Confirm the measurement parameters.
When detector parameter is set to "Option2", liquid nitrogen
sensor is active and if there is no liquid N
this error message is shown. Confirm that MCT dewer is
filled with liquid N and that cable is connected.
2
Power spectrum shape check in diagnostics has failed.
Execute [Measurement]-[Auto Adjust] and try again.
Power spectrum shape check in diagnostics can not be
completed. Execute [Measurement]-[Auto Adjust] and try
again.
Piezo voltage check in diagnostics has failed. Execute
[Measurement]-[Auto Adjust] and try again.
Piezo voltage check in diagnostics can not be completed.
Execute [Measurement]-[Auto Adjust] and try again.
The remaining memory in your PC is insufficient. If you are
using other applications on the PC, terminate other
applications and restart the PC.
Moving mirror movement has failed. Execute
[Measurement]-[Auto Adjust] and try again
Moving mirror movement has failed. Execute
[Measurement]-[Auto Adjust] and try again
The QC counter to manage the moving mirror position shows
an abnormal value. Scan samples isolated from vibrations.
The moving mirror could not finish its operation. Execute
[Measurement]-[Auto Adjust].
in the MCT dewer,
2
