The intensity specifications are given below.
Wavenumber (cm
4600:
4000:
3000:
Wavenumber indicating the maximum intensity
(2500 - 1800 cm
700:
500:
1)
403 :
351:
1) There is an absorbance peak of water at 400 cm
is not calculated. Thus the intensity of 403 cm
If the intensity does not meet the specifications, or the energy at high wavenumbers (to 4600 cm
low, run [Auto adjustment] on the [Instrument] Menu, and reanalyze the spectrum. If the power spectrum does
not improve after the "auto adjustment", the system may be damaged; contact your SHIMADZU representative.
If the intensity remains zero, the light source may be disconnected or damaged; light source replacement or
repair should be performed by a SHIMADZU service engineer.
5.1 Start-Up Inspection and Periodic Inspection
−1
):
−1
):
Fig. 5.4 Power Spectrum (Example)
Specification
10% or more of maximum
25% or more of maximum
50% or more of maximum
50 or more
10% or more of maximum
2% or more of maximum
0.5% or more of maximum
0.01% or more of maximum
−1
, so correct intensity of the power spectrum
−1
is used for evaluation of the power spectrum.
