Shimadzu IRAffinity-1 Instruction Manual page 52

Chapter 3 Installation
12. The [Select Components] dialog box opens. Select components of the IRsolution main
components to be installed. The following components can be installed.
Setup
Program
Help
GLP mode
Support for hardlock
protected libraries
DataExtractor support
Support for Sadtler
hardlock
13. Check the necessary components. Click the [Next] button after setting.
IRAffinity-1
3-10
Table 3.1 "Setup Components"
Description
The IRsolution main body
Help message file of the IRsolution
Installs the IRsolution on the GLP mode to support the GLP/GMP. Electric
Signature function is available on the GLP mode. You cannot switch the GLP/
non-GLP mode after installation.
Installs the hardlock driver to use protected libraries with a protection key
(dongle).
Is checked, when used with the CLASS-Agent/IRsolution Agent.
Installs the hardlock driver to use Sadtler libraries.
Fig. 3.8 [Select Components] Dialog Box
