Shimadzu IRAffinity-1 Instruction Manual page 13

WARNING
Compliance with Laser Requirements
The IRAffinity-1 is classified Class 1 laser product according to IEC60825-1: 1993 + A1: 1997 + A2: 2001
and the U.S. FDA 21CFR Part 1040.10/1040.11 except for deviations pursuant to Laser Notice No.50 dated
June 24, 2007. And the IRAffinity-1 uses a Class 2 helium neon laser with an output of 0.5 mW, maximum in
it. When the IRAffinity-1 is on, the laser is emitted continuously. It has two purposes in the system: sampling
signal generation and optical axis adjustment.
When the IRAffinity-1 cover is on, the sampling signal laser is not visible. However, the optical alignment
laser, a weak beam with 1/5 of the laser output (0.1 mW, maximum), is continuously emitted into the work
area.
Optical Specification
Wavelength: CW 632.8 nm
Optical Power: 0.1 mW, maximum
Laser label (Part No.037-70839-01)
IRAffinity-1
xi
