Chapter 4 Operations

4.1 Activation and Shutdown of IRAffinity-1 and
PC
4.1.1

Activation

1. Turn on the power switch of IRAffinity-1.
2. Turn on the personal computer (PC). After the system check, Windows starts automatically.
NOTE
When the IRAffinity-1 is activated, internal elements of IRAffinity-1 are initialized. Be careful
because an auto-sample connected to the IRAffinity-1 will start initialization.
Even if the auto-sample was initialized when IRAffinity-1 was on, it must be initialized by
IRsolution software.
4.1.2

Quitting

To turn off the IRAffinity-1 system, follow the directions below.
1. Confirm that all necessary IRsolution data has been saved.
2. Quit IRsolution with the [File] - [Exit] command.
3. Quit Windows.
4. Verify that there is no remaining disk activity by checking the access indicator on the front
panel of the PC, and turn off the PC.
5. Turn off the power switch at the front right side of the IRAffinity-1. The power indicator (green)
should turn off.
6. Keep a power supply cable connected to IRAffinity-1 to run the internal auto dehumidifier. The
orange lamp will remain on.
NOTE
To avoid system damage, do NOT turn off or restart the computer while running Windows.
IRAffinity-1
4-2
Fig. 4.1 IRAffinity-1
Power switch
