Digi XBee S2C Zigbee User Manual page 319

Part number Type (description)
A24-F3NF Omni-directional
(Fiberglass base
station)
A24-F5NF Omni-directional
(Fiberglass base
station)
A24-F8NF Omni-directional
(Fiberglass base
station)
A24-F9NF Omni-directional
(Fiberglass base
station)
A24-F10NF Omni-directional
(Fiberglass base
station)
A24-F12NF Omni-directional
(Fiberglass base
station)
A24-F15NF Omni-directional
(Fiberglass base
station)
A24-W7NF Omni-directional (Base
station)
A24-M7NF Omni-directional (Mag-
mount base station)
Gain Min.
1
(dBi) separation
Application
3.0 Fixed/Mobile 20 cm
5.0 Fixed/Mobile 20 cm
8.0 Fixed 20 cm
9.5 Fixed 20 cm
10.0 Fixed 20 cm
12.0 Fixed 20 cm
15.0 Fixed 20 cm
7.2 Fixed 20 cm
7.2 Fixed 20 cm
Required cable-loss Required cable-
or power reduction loss or power
from +8 dBm reduction from +8
channels 11 to 24 dBm channel 25
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0 0
Required cable-loss
or power reduction
from +1 dBm
channel 26
0
0
0
1.5
2.5
4.5
7.5
0
0
