I/O settings commands

The following AT commands are I/O settings commands.

D0 (AD0/DIO0 Configuration)

This command applies to the XBee/XBee-PRO Zigbee RF Module.
Sets or displays the DIO0/AD0 configuration (TH pin 20/SMT pin 33).
Parameter range
0 - 5
Parameter
0
1
2
3
4
5
Default
1

D1 (AD1/DIO1/PTI_En Configuration)

This command applies to the XBee/XBee-PRO Zigbee RF Module.
Sets or displays the AD1/DIO1/PTI_En configuration TH pin 19/SMT pin 32.
Parameter range
0 - 6
Parameter
Description
0
Unmonitored digital input
SPI_ATTN - Analog input, single ended for the through-hole device
1
2
Analog input, single ended
XBee/XBee-PRO® S2C Zigbee® RF Module User Guide
Description
Unmonitored digital input
Commissioning Pushbutton
Analog input, single ended
Digital input
Digital output, low
Digital output, high
I/O settings commands
275
