Frame descriptions

Examples

Each example is written without escapes (AP = 1) and all bytes are represented in hex format. For
brevity, the start delimiter, length, and checksum fields have been excluded.
Identify remote device
A technician is replacing a DigiMesh device in the field and needs to have the its entry removed from a
cloud server's database. The technician pushes the commissioning button on the old device once to
send an identification broadcast. The server can use the broadcast to identify which device is being
replaced and perform the necessary action.
When the node identification broadcast is sent, every device that receives the message will flash the
association LED and emit the following information frame:
7E 00 27 95 00 13 A2 00 12 34 56 78 FF FE C2 FF FE 00 13 A2 00 12 34 56 78 4C
48 37 35 00 FF FE 01 01 C1 05 10 1E 00 14 00 08 0D
Frame 64-bit
type source
0x0013
0x95
A200
123456
78
Identific
ation
Identify joining device
A Zigbee end device has join notification enabled by setting JN to 1. When the joining device
successfully associates with a Zigbee network, it will broadcast a node identification message.
The network has a variety of devices that are assigned identifier strings after association; a unique DD
value is set to identify this type of device. The gateway that manages the network has
the NO command set to 1 to display this information.
When the node identification broadcast is sent, every device that receives the message will flash the
association LED and emit the following information frame:
7E 00 24 95 00 13 A2 00 87 65 43 21 77 92 02 77 92 00 13 A2 00 87 65 43 21 20
00 45 A3 02 02 C1 05 10 1E 00 12 00 27 13
Frame
type
0x0013
0x95
XBee/XBee-PRO® S2C Zigbee® RF Module User Guide
16-bit 16-bit
sourc Optio remo 64-bit
e ns te remote NI String
0x0013
0xFFF 0xC2 0xFFF
A200
E E
123456
78
Unkn DigiM Unkn
own esh own
broad
cast
64-
bit 16-bit
sou sourc Opti 16-bit
rce e ons remote
0x0013
0x77 0x02 0x77
Node Identification Indicator - 0x95
Dev
Paren ice
t type
0x4C4837 0xFFF 0x01 0x01 0xC1
35 00 E
"LH75" + Unkn Rout
null own er
64-
bit NI Dev
rem Stri Par ice
ote ng ent type
0x20 0x45 0x02 0x02 0xC
Prof
Eve ile MFG
nt ID ID
0x10
05 1E
Butt Digi Digi
on
pres
s
Prof
Eve ile DD
nt ID value
0x10 0x0012
