Digi XBee S2C Zigbee User Manual page 314

Part number Type (description)
A24-F2NF Omni-directional (Fiberglass base station)
A24-F3NF Omni-directional (Fiberglass base station)
A24-F5NF Omni-directional (Fiberglass base station)
A24-F8NF Omni-directional (Fiberglass base station)
A24-F9NF Omni-directional (Fiberglass base station)
A24-F10NF Omni-directional (Fiberglass base station)
A24-F12NF Omni-directional (Fiberglass base station)
A24-W7NF Omni-directional (Fiberglass base station)
A24-M7NF Omni-directional (Mag-mount base station)
A24-F15NF Omni-directional (Fiberglass base station)
Yagi antennas
A24-Y6NF Yagi (6-element)
A24-Y7NF Yagi (7-element)
A24-Y9NF Yagi (9-element)
A25-Y10NF Yagi (10-element)
A24-Y12NF Yagi (12-element)
A24-Y13NF Yagi (13-element)
A24-Y15NF Yagi (15-element)
A24-Y16NF Yagi (16-element)
A24-Y15RM Yagi (16-element, RPSMA connector)
A24-Y18NF Yagi (18-element)
Gain Min
(dBi) Application* separation
2.1 Fixed/Mobile 20 cm
3.0 Fixed/Mobile 20 cm
5.0 Fixed 20 cm
8.0 Fixed 2 m
9.5 Fixed 2 m
10.0 Fixed 2 m
12.0 Fixed 2 m
7.2 Fixed 2 m
7.2 Fixed 2 m
15.0 Fixed 2 m
8.8 Fixed 2 m
9.0 Fixed 2 m
10.0 Fixed 2 m
11.0 Fixed 2 m
12.0 Fixed 2 m
12.0 Fixed 2 m
12.5 Fixed 2 m
13.5 Fixed 2 m
13.5 Fixed 2 m
15.0 Fixed 2 m
Required antenna cable loss
(dB)
N/A
N/A
N/A
N/A
N/A
N/A
2.0
N/A
N/A
5.0
3.8
4.0
5.0
6.0
7.0
7.0
7.5
8.5
8.5
10.0
