Status Transparent
code mode string Description
0x12 Rejected(cmdL Rejected because it matches the last
ast) associated network.
0x13 Rejected(cmdS Rejected because it matches an already
ave) saved beacon response.
0x14 Reject strength During first/best phase, response is weaker
than an already saved beacon response.
0x16 Reset for DC80 With DC80 enabled, reset if no joinable
beacon responses are received within 60s
of joining.
0x18 ScanCh Scanning on Channel
0x19 Scan Mode Shows phase of Ordered Association.
0x1A Scan Init Starting a scan
0x1D Energy Scan - Starting energy scan
channel mask
0x1E Energy Scan - Channel Energies observed
energies
0x1F PanIdScan - Pan Id Scan starting on channel
radio channel
0x20 FormNetwork - Forming a network
parameters
Status data Description
radioChannel(1) channel number ranging from 11 to 26 (0x0B to 0x1A)
0: first/bestcandidate
mode(1)
1: ordered association by extpanid, then by channel
channel being scanned
channel(1) TxPower
low level radio transmit power setting
(1)
SC mask(4)
Scan channel mask
Energy Levels per channel in SC
Energies(16)
channel(1) Radio Channel
radioChannel(1) channel number ranging form 11 to 26
radioTxPower(1) low level radio transmit power setting
panid(2) 16 bit PAN identifier for network
extendedpanid(8) 64 bit PAN identifier for network
