Frame descriptions
Offset Size
EOF 8-bit

Examples

Each example is written without escapes (AP = 1) and all bytes are represented in hex format. For
brevity, the start delimiter, length, and checksum fields have been excluded.
4-hop route
A remote device sends a unicast transmission to a concentrator that is 4-hops away. The concentrator
emits a route record that can be stored for use in a
prior to sending data back to the remote.
The route looks like this:
Destination (concentrator) <> Router A <> Router B <> Router C <> Source (remote)
7E 00 13 A1 00 13 A2 00 12 34 56 78 DD DD 01 03 CC CC BB BB AA AA 75
Frame 64-bit
type source
0x0013A200
0xA1
12345678
Route Source IEEE
address
XBee/XBee-PRO® S2C Zigbee® RF Module User Guide
Frame
Field Description
Checksum 0xFF minus the 8-bit sum of bytes from offset 3 to this byte
(between length and checksum).
16-bit Num of
source Options addresses
0xDDDD 0x01 0x03
Source 3
NWK
address
Route Record Indicator - 0xA1
subsequent Create Source Route -
Address
1 Address 2
0xCCCC 0xBBBB
Neighbor Intermediate
of source hop
0x21 frame
Address 3
0xAAAA
Neighbor of
destination
