D4 (Dio4 Configuration); D5 (Dio5/Associate Configuration) - Digi XBee S2C Zigbee User Manual

AT commands
Parameter
1
2
3
4
5
Default
0

D4 (DIO4 Configuration)

This command applies to the XBee/XBee-PRO Zigbee RF Module.
Sets or displays the DIO4 configuration (TH pin 11/SMT pin 24).
Parameter range
0, 1, 3 - 5
Parameter
0
1
3
4
5
Default
0

D5 (DIO5/Associate Configuration)

This command applies to the XBee/XBee-PRO Zigbee RF Module.
Sets or displays the DIO5 configuration (TH pin 15/SMT pin 28).
Parameter range
0, 1, 3 - 5
Parameter
0
1
XBee/XBee-PRO® S2C Zigbee® RF Module User Guide
Description
SPI_SSEL for the through-hole device
Analog input, single ended
Digital input
Digital output, low
Digital output, high
Description
Unmonitored digital input
SPI_MOSI for the through-hole device
Digital input
Digital output, low
Digital output, high
Description
Unmonitored digital input
Associate LED indicator - blinks when associated
I/O settings commands
277
