Fimap MAXIMA Quick Start Manual page 3

Adjustment brush – SINGLE BRUSH 450-500 B-BT / MOVEMENT SEMI-AUTOMATIC B
1. Adjust the spring belt tightener
inches) in compression
2. The adjustment lever for the height
under the machine, has to be adjusted always with the brush
base lowered onto the floor, without the brush. Check that
the lifting lever is in the highest point of the sliding slit, without
hitting or forcing onto the frame. Furthermore, check that it slides
to the right and to the left, with the lever stop being free.
3. To get the correct functioning, act upon the screw
the lever under the machine, by screwing down or unscrewing until
the rear lever is brought into its correct position, then block the
.
lock nut M8
4. The brush adjustment for the machines without traction and
therefore with a movement depending on the brush rotation, has
to be carried out as follows:
• Lower the brush base, applying in the front part of the cover a
metal bar of 15mm
unscrew the screw M6
• Unscrew the screw M8
base downwards and block the screw previously unscrewed, screw
down the screw M6 until it touches lightly the base.
• Couple the brush, always with the brush base in working position,
and unscrew the
the screw as soon as the brush base fixing is obtained.
• Adjust the traction effect on hand of the screw M6, then block the
lock nut.
ADJUSTMENTS
AND
INSPECTIONS
at a length of 27mm (1,06
.
between the cover and the floor, and
on top of the cover.
of the brush inclination, push the complete
screw M8 for the brush inclination, then block
MAXIMA
of the brush base placed
M8 placed on
Doc. 10004809
Emesso dec -06
Rev. 00
Pag. 3 di 7
