Summary of Contents for Fimap MY 16 B
- Page 1 USE AND MAINTENANCE MANUAL MY 16 B ED. 09-2019 Doc. 10012153 Ver.
- Page 2 The descriptions contained in this document are not binding. The company therefore reserves the right to make any modifications at any time to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements. The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
-
Page 3: Table Of Contents
CONTENTS ON CONSIGNMENT OF THE MACHINE ..............................4 SERIAL NUMBER PLATE ..................................4 INTRODUCTORY COMMENT ................................4 INTENDED USE ....................................4 TECHNICAL DESCRIPTION .................................. 5 SYMBOLS USED ON THE MACHINE ..............................6 GENERAL SAFETY REGULATIONS ............................... 7 ... -
Page 4: On Consignment Of The Machine
On consignment of the machine Serial number plate When the machine is consigned to the customer, an immediate check must be performed to ensure all the material mentioned in the shipping documents has been received, and also to check the machine has not suffered damage during transportation. -
Page 5: Technical Description
TECHNICAL DESCRIPTION My16 B Nominal input power [IEC 60335-2-72; IEC 62885-9] 0,61 Working width Width of rear squeegee Working capacity 1520 mm Brushes (diameter or length) Brush rpm Force exerted on brush Brush motor V / W 12 - 360 Forward speed type semi-aut. -
Page 6: Symbols Used On The Machine
SYMBOLS USED ON THE MACHINE Tap symbol Used to indicate the solenoid valve switch Brush symbol Used to indicate the brush motor switch Symbol denoting vacuum motor Used to indicate the suction motor switch Battery symbol Battery charge level indicator Indicates the maximum temperature of the detergent solution Located near the solution tank inlet Indicates the risk of crushed hands... -
Page 7: General Safety Regulations
GENERAL SAFETY REGULATIONS Before using the machine, please read the following document carefully and follow the instructions contained herein, along with the instructions in the document supplied with the machine itself, "GENERAL SAFETY REGULATIONS" (document code 10083659). -
Page 8: Machine Preparation
MACHINE PREPARATION 1. HANDLING THE PACKED MACHINE The machine is contained within specific packaging. Every pallet consists of two machines arranged side by side. It is not possible to place more than two packages on top of each other. The total weight is kg72 The overall dimensions of the package are: A : 102,5 mm B: 85,5 mm... -
Page 9: Type Of Battery
ATTENTION: You are advised to use airtight batteries only, to avoid the leakage of acids! ATTENTION: you are advised to have the electric connections made by a qualified, FIMAP-trained technician ATTENTION: users are advised to always wear protective gloves, to avoid the risk of serious injury to hands. -
Page 10: Connecting The Connector
MACHINE PREPARATION 7. CONNECTING THE CONNECTOR Connect the battery connector to the machine connector located above the battery compartment. ATTENTION: This process must be carried out by qualified personnel. The incorrect or imperfect connection of the cables to the connector can seriously harm people and damage objects 8. -
Page 11: Charging The Battery (Without Built-In Battery Charger)
PREPARATION OF MACHINE ATTENTION: The machine is equipped with an automatic system that disconnects the power supply from the electrical system while the batteries are being recharged ATTENTION: In order not to cause permanent damage to the batteries, it is essential to avoid their complete discharge: arrange the recharge within a few minutes of the switching on of the "discharged batteries"... -
Page 12: Battery Indicator
PREPARATION OF MACHINE 10. BATTERY INDICATOR The battery indicator is digital, with 4 fixed positions and a flashing one. The numbers that appear on the display show the approximate charge level. 4 = maximum charge, 3 = 3/4 charge, 2 = 2/4 charge, 1 = 1/4 charge, 0 = batteries run down (flashing) ATTENTION: A few seconds after the appearance of the flashing “0”, the brush motor switches off automatically. -
Page 13: Lid
PREPARATION OF MACHINE 2. Water-solution inlet cap 3. Solution tank cap-filter 14. LID Check the lid is correctly inserted beneath the protruding command panel. ATTENTION: Hand crushing hazard 15. SOLUTION TANK Check that the water-solution filler cap is correctly screwed on. Verify that the cap is correctly screwed into its housing (B). -
Page 14: Regulating The Detergent Solution
PREPARATION OF MACHINE The solution tank has a maximum capacity of about 20 litres. Add the liquid detergent to the tank in the concentration and manner indicated on the detergent manufacturer's label. The formation of excess foam could damage the vacuum motor, so use only the minimum amount of detergent that is necessary. ATTENTION: always use detergents whose manufacturer's label indicates their suitability for scrubbing machines. -
Page 15: Work
WORK 1. PREPARING TO WORK 1. Connect the electric system connector (2) to the battery connector (1) ATTENTION: before using the machine, the operators must be suitable trained. We therefore recommend you read this instruction booklet carefully, and consult it whenever difficulties arise while using the machine. 2. -
Page 16: Overflow Device
WORK 2. OVERFLOW DEVICE The machine is fitted with a ball filter which is activated when the recovery tank is full, causing the suction tube to close. In this case, it is necessary to switch off the machine and empty the recovery tank. ATTENTION: This operation must be carried out wearing gloves to protect against contact with dangerous solutions. -
Page 17: At The End Of The Work
AT THE END OF THE WORK At the end of the work, and before carrying out any type of maintenance, perform the following operations: 1. Turn off the solenoid valve switch (3) 2. Turn off the suction switch (2) 3. Turn off the brush / main switch (1) 4. -
Page 18: Daily Maintenance
DAILY MAINTENANCE PERFORM ALL MAINTENANCE OPERATIONS IN SEQUENCE CLEANING THE RECOVERY TANK 1. grasp the tube on the rear of the machine 2. Remove the drainage cap and empty the tank ATTENTION: Before carrying out any type of maintenance, disconnect the machine's battery connector. ATTENTION: This operation must be carried out wearing gloves to protect against contact with dangerous solutions. -
Page 19: Disassembling The Brush
DAILY MAINTENANCE 3. DISASSEMBLING THE BRUSH 1. Lower the rear lever. 2. Pressing with your foot, raise the base. 3. With the base in the raised position, activate the brush main switch with impulses. The brush will be automatically released 4. -
Page 20: Weekly Maintenance
WEEKLY MAINTENANCE 1. CLEANING THE SQUEEGEE TUBE Periodically, or whenever suction seems to be unsatisfactory, verify that the squeegee tube is not obstructed. To clean it, proceed as follows: 1. remove the tube from the sleeve on the squeegee 2. remove the other end from the recovery tank 3. -
Page 21: Cleaning The Solution Tank And Filter
WEEKLY MAINTENANCE 3. CLEANING THE SOLUTION TANK AND FILTER 1. Loosen the solution tank cap 2. Remove the filter and clean it. 3. Rinse the solution tank with a jet of water. 4. Reassemble the filter and cap. ATTENTION: This operation must be carried out wearing gloves to protect against contact with dangerous solutions. -
Page 22: Troubleshooting
To restore the power supply to the motor, switch off the machine and wait for a few minutes. If the protection devices intervene again, contact the FIMAP technical assistance centre. 2. INSUFFICIENT WATER ON THE BRUSHES 1. -
Page 23: Choosing And Using The Brushes
It is fitted with a series of tufts of bristles that allow the abrasive floor pad to be held and dragged while working. TABLE FOR CHOOSING THE BRUSHES Machine Code Type of bristles Bristles Brush Notes No. of brushes 429372 My 16 B 428782 429371 Pad holder... -
Page 24: Machine Disposal
MACHINE DISPOSAL Proceed with scrapping the machine in accordance with the waste disposal regulations in force in the country in which the machine is being used... -
Page 25: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY The undersigned manufacturer: FIMAP S.p.A. Via Invalidi del Lavoro, 1 37059 Santa Maria di Zevio (VR) declares under its sole responsibility that the products FLOOR SCRUBBING MACHINES mod. My16 B CB comply with the provisions of Directives: 2006/42/EC: Machinery Directive. - Page 26 The undersigned manufacturer: FIMAP S.p.A. Via Invalidi del Lavoro, 1 37059 Santa Maria di Zevio (VR) declares under its sole responsibility that the products FLOOR SCRUBBING MACHINES mod. My16 B comply with the provisions of Directives: 2006/42/EC: Machinery Directive. 2014/30/EC: Electromagnetic compatibility directive.
- Page 28 FIMAP - Via Invalidi del Lavoro, 1 - 37059 S. Maria di Zevio - Verona - Italy Tel. +39 045 6060411 - Fax +39 045 6060417 - E-mail: fimap@fimap.com www.fimap.com...
