Assembly
A
Installation spacing
d
d > 100 mm
d

Mains connection

B
Danger!
!
,
Switch off power supply.
,
Dangerous voltage: The power terminals may carry dangerous voltages for some time even if the
power supply is switched off. Wait for some minutes before starting to work at the frequency inverter.
,
Make sure that the frequency inverter is de-energized.
,
Do not carry out high voltage insulation tests on cables connected to the frequency inverter.
,
Use copper wire rated at 30 °C.
, Connect mains supply.
!
B
3
400 V 400 V
PE
F1
L3
F1
L2
F1
L1
X1
Connection on IT mains configuration
For connection on IT mains configuration remove the IT-jumper.
Note:
The removement of the IT-jumper reduces the noise immunity. The noise
immunity can be improved by external filters.
F1
L1, N
0.5 Nm
PE
or
Note:
:
Only required for DC-link connections.
5
kW 0.25 ... 1.5 2.2 3.0 4.0
A 6 10 10 10
2
mm
1.5
2
mm
2 x 1.5
1 x 10
GB
5.5 7.5 9.2 11
25 25 35 35
2.5 4
2 x 2.5 2 x 4
1 x 10 1 x 10
2
mm
AWG
1.5 16
2.5 14
4 12
10 8
