8
Turn off power supply for Unisab III
and disconnect all plug connections
exept the power connection (X20).
Reconnect power supply for Unisab III
Does display turn on as normal?
Reconnect all plug connections one by
one in attempt to locate the error
Fig. 61: Error diagram no. 9
Check voltage on terminals
(X4/3-4) = 24 VDC
Is voltage ok
No
Yes
If unsuccessful, contact
Johnson Controls Denmark
316/346
Yes
Contact Johnson Controls Denmark
No
Contact Johnson Controls Denmark
Engineering manual - UniSAB III 1.10.8
Troubleshooting
001930 en 2021.06
