Service
5.1.5

Trend information

UniSAB III provides the possibility to log Trend data for export by e-mail to the remote monitoring server.
Set-up for Trend files logging and handling is made in this picture.
No.
1 Resolution (trend log resolution)
2 Period (time between trend mails)
3 Zip (zip the trend file attachment)
Parameter list
4
(bit map for parameter list)
Note: The Zip function is implemented from version 1.0.9.6.
Note that the memory constraint in UniSAB III will set a limit of maximum 500 data log per trend e-mail.
Depending on the set resolution the period setting must be limited as shown in Table 36.
Resolution
[Sec.]
30
60
90
180
300
Table 36
Engineering manual - UniSAB III 1.10.8
001930 en 2021.06
Service/Trend
Function
Period [Hours]
Max. allowable setting
171/346
Use
1/2 180, [30-300]
1/2 4, [1-24]
1/2 No, Yes
4.294.967.295
1/2
(~ FFFF FFFF
4
8
12
24
24
Choices
10
~ bit map = 32)
hex
Max. data logs
per trend e-mail
480
480
480
480
288
