Hawkeye® 2 Installation
Manual for AGCO Fendt
RoGator 900 Series
016-2005-009 Rev. A
4/2022
E40897
Copyright 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hawkeye 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Raven Hawkeye 2

Summary of Contents for Raven Hawkeye 2

  • Page 1 Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series 016-2005-009 Rev. A 4/2022 E40897 Copyright 2022...
  • Page 2 Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services. Raven Industries accepts no responsibility for the use of any of these signals or services for other than the stated purpose.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Important Information..................1 Safety ....................................1 Agricultural Chemical Safety .............................. 2 Electrical Safety ..................................2 Recommendations and Best Practices ........................ 3 Harness Routing ..................................3 Chapter 2 Introduction......................5 Make and Model Compatibility ..........................5 Section Spacing ..................................5 Machine Configuration Notes ............................
  • Page 4 Table of Contents Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...

  • Page 5: Important Information

    • Do not operate this Raven system or any agricultural equipment while under the influence of alcohol or an illegal substance. • Be alert and aware of surroundings and remain in the operator seat at all times when operating this Raven system.

  • Page 6: Agricultural Chemical Safety

    • Do not connect the power leads to the battery until all system components are mounted and all electrical connections are completed. • Always start the machine before initializing this Raven system to prevent power surges or peak voltage. • To avoid tripping and entanglement hazards, route cables and harnesses away from walkways, steps, grab bars, and other areas used by the operator or service personnel when operating or servicing the equipment.

  • Page 7: Recommendations And Best Practices

    The word “harness” is used to describe any electrical cables and leads, both bundled and unbundled. Use the following guidelines and recommendations when connecting and routing harnesses while installing or maintaining this Raven system: • Leave protective caps/covers over harness connectors until needed to avoid dirt and moisture from contaminating electrical circuits.
  • Page 8 CHAPTER 1 Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...

  • Page 9: Introduction

    I NTRODUCTION CHAPTER C H A P T E R 2 MAKE AND MODEL COMPATIBILITY Hawkeye® 2 is a pressure-based product control system which allows for precise sprayer application over a range of conditions and reduced spray drift. Each nozzle is controlled by an individual pulsing valve giving you a consistent spray pattern as speed and conditions change.
  • Page 10 Utilize Table 2 and 3 for 15/16 section capabilities. Utilize Table 4 and 5 for 35/36 section capabilities. This is determined by the combination of the AGCO RoGator C ECU and Raven RCM - Sprayer ECU software versions and unlock levels. The configuration wizard will limit this automatically.
  • Page 11 INTRODUCTION AGCO RoGator C, 36 Section Breakdown (90’-100’) TABLE 4. 90’/ 90’/ 90’/ 100’/ 100’/ 100’/ 100’/ Switch Section 10” 15” 20” 10” 15” 19” 20” Introduction: Make and Model Compatibility...
  • Page 12 CHAPTER 2 AGCO RoGator C, 36 Section Breakdown (120’-132’) TABLE 5. 120’/ 120’/ 120’/ 120’/ 120’/ 132’/ 132’/ 132’/ Switch Section 10” 15” 19” 20” 20” AL 15” AL 19” AL 20” AL Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...

  • Page 13: Machine Configuration Notes

    Provider. For 36 section control, the AGCO RoGator C / 900 Series Liquid EXT software must be updated to version 1.02 or newer. • The Raven RCM - Sprayer ECU must be updated to software version of v21.2.1.7 or newer. • When prompted to setup the machine configuration, complete the following steps:...
  • Page 14 CHAPTER 2 4. For each section, use the color coordination in the tables above to select which switch the section will be mapped to as shown in Figure 2, “Switch Mapping - Assigning Sections,” below. NOTE: Only use numbers 1-5 in the drop-down list for each section according to the color code in the tables. FIGURE 2.

  • Page 15: Installation Overview

    • Updated software on field computers or control monitors and other ECUs. Contact your local AGCO dealer for the latest software. • PWM pump control valve • Raven compatible flow meter • Raven compatible pressure transducer • 80 mesh (or finer) strainer...

  • Page 16: Kit Contents

    CHAPTER 2 KIT CONTENTS Kit Contents for AGCO RoGator C-Series Equipment with Hypro Nozzle TABLE 6. Bodies Qty. Item 117-2005- Part Number Description Sheet, Warranty/ 016-0171-649 Help Cable, PWR Distribution, 115-2005-366 AGCO R9, Hawkeye® 2 Cable, Left/Right, AGCO R9, 115-2005-367 Hawkeye®...
  • Page 17 INTRODUCTION Qty. Item 117-2005- Part Number Description O-ring, Viton, 219-2005- Purple, Size -115, 115M 38 Pack Nozzle Body, Hypro 5-way 333-0002-359 turret, AGCO, Left Port Cable, Mid, AGCO, 90’/15” 115-2005-189 Hawkeye® 2 Cable, Outer, AGCO, 90’/15” 115-2005-350 Hawkeye® 2 Cable, Mid, AGCO, 90’/20”...
  • Page 18 CHAPTER 2 Qty. Item 117-2005- Part Number Description Cable, Mid, AGCO, 120’/19” 115-2005-177 Hawkeye® 2 Cable, Outer, AGCO, 120’/19” 115-2005-178 Hawkeye® 2 Cable, Mid, AGCO, 120’/20” 115-2005-003 Hawkeye® 2 Cable, Outer, AGCO, 120’/20” 115-2005-004 Hawkeye® 2 Cable, Mid, AGCO, 132’/15” 115-2005-381 Hawkeye®...
  • Page 19 INTRODUCTION Qty. Item 117-2005- Part Number Description Cable, Outer, 100’/15”, 115-2006-028 RoGator C/900, HF, Hawkeye® 2 Cable, Left Inner, AGCO, 90’/15”, 115-2005-187 Hawkeye® 2 Cable, Right Inner, AGCO, 90’/ 115-2005-188 15”, Hawkeye® 2 Cable, Inner, AGCO, 90’/20”, 115-2005-123 Hawkeye® 2 Cable, Left Inner, AGCO, 100’/19”, 115-2005-179...
  • Page 20 CHAPTER 2 Qty. Item 117-2005- Part Number Description Cable, Right Inner, AGCO RoGator C/900, 115-2005-184 120’/15”, Hawkeye® 2 Cable, Left Inner, AGCO, 132’/19”, 115-2005-151 Hawkeye® 2 Cable, Right Inner, AGCO, 115-2005-152 132’/19”, Hawkeye® 2 Cable, Inner, AGCO, 132’/20”, 115-2005-159 Hawkeye® 2 Cable, Left Inner, AGCO, 120’/15”, 115-2006-021...
  • Page 21 INTRODUCTION Hawkeye® 2 Service Kit Components for Wilger Nozzle Bodies (P/N 117- TABLE 7. 2005-052) Picture Item Description Part Number Quantity Nozzle Control Valve, Hawkeye® 2, 063-2005-003 Wilger Kit, Individual Repair, Hawkeye® 2 Not Pictured 117-2005-062 NCV, Wilger Cable, Hawkeye® 2 8-pin Ampseal 115-2005- Not Pictured Jumper...

  • Page 22: Updates

    CHAPTER 2 UPDATES Raven software and documentation updates may be made available periodically on the Raven Applied Technology web site: www.ravenprecision.com At Raven Industries, we strive to make your experience with our products as rewarding as possible. One way to improve this experience is to provide us with feedback on this manual.

  • Page 23: Chapter 3 Installation Preparation

    I NSTALLATION PREPARATION CHAPTER C H A P T E R 3 Perform the following procedure to prepare for the Hawkeye® 2 system installation. CAUTION Chemical residues may be present. Thoroughly bleed pressure from chemical lines and rinse the system with clean water prior to installing or servicing fittings, hoses, valves, or nozzles in the application system.
  • Page 24 CHAPTER 3 Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...

  • Page 25: Nozzle Body And Nozzle Control Valve Installation

    N OZZLE BODY AND NOZZLE CHAPTER C H A P T E R 4 CONTROL VALVE INSTALLATION HAWKEYE® 2 NOZZLE BODY INSTALLATION After completing the steps in Chapter 3, Installation Preparation, install the provided nozzle bodies and nozzle control valves. BEST PRACTICES AND RECOMMENDATIONS •...

  • Page 26: Install The Prostop-E Valve

    CHAPTER 4 2. Remove existing Hypro 5-way, right-handed nozzle bodies from the sprayer by unscrewing the Phillips screw located in the clamp. 3. Install the left-handed nozzle bodies, replacing all right-handed nozzle bodies. NOTE: Boom tube support brackets my need to be adjusted to provide clearance for left-handed nozzle bodies and NCV2s.
  • Page 27 NOZZLE BODY AND NOZZLE CONTROL VALVE INSTALLATION 2. Remove the ProStop-E valve from the original Hypro nozzle body by removing the U-clip that attaches it to the threaded nut. Pull on the valve to separate it from the nut, and spin the nut to remove it from the nozzle body. NOTE: Leave the ProStop-E connected to the existing cabling.
  • Page 28 CHAPTER 4 BUMPER INSTALLATION FOR MACHINES WITH PROSTOP-E VALVES AND WILGER NOZZLE BODIES It is necessary to add spacers to the boom bump stops to help prevent nozzle bodies from colliding with each other upon folding, causing damage to the nozzle bodies. To install bump stop spacers: 1.

  • Page 29: Nozzle Control Valve 2 (Ncv2) Installation

    NOZZLE BODY AND NOZZLE CONTROL VALVE INSTALLATION NOZZLE CONTROL VALVE 2 (NCV2) INSTALLATION 1. Locate the Hawkeye® 2 NCVs and the O-rings provided with the kit. NOTE: Hypro NCV2 and nozzle body will use the purple-colored (size 115) O-rings (P/N 219-2005-115) Wilger NCV2 and nozzle body will use the black-colored (size 116) O-rings (P/N 219-2005-116) 2.

  • Page 30: Boom Cable Routing And Connections (Inner, Middle, And Outer Boom Cables)

    CHAPTER 4 BOOM CABLE ROUTING AND CONNECTIONS (INNER, MIDDLE, AND OUTER BOOM CABLES) 1. Locate the boom cables included with the Hawkeye® 2 installation kit. There are typically six boom cables for a single system: • 2 inner boom cables (may be left and right specific). •...

  • Page 31: Chapter 5 Chassis Cable Installation

    C HASSIS CABLE INSTALLATION CHAPTER C H A P T E R 5 CHASSIS CABLE ROUTING AND CONNECTION BEST PRACTICES AND RECOMMENDATIONS • Ensure the battery is not connected during the installation. • Route chassis cabling along existing cabling or plumbing to help avoid pinch points or stretching the cable during normal equipment operation.
  • Page 32 CHAPTER 5 3. Use a 1-1/2” hole saw to drill two holes through the bottom of the power distribution cabinet to allow passage of the bulkhead connections of the Hawkeye® 2 power distribution cable (P/N 115-2005-366). NOTE: While facing the cabinet, the recommended location for these ports is towards the right half of the removable bottom plate section of the cabinet as shown in Figure 2, “Power Distribution Cabinet with Hawkeye®...

  • Page 33: Hawkeye® 2 Right/Left Cable Installation

    2. Connect the two 8-pin bulkhead connectors to the mating connectors mounted to the bottom panel of the power distribution cabinet. Match both right connectors and both left connectors together. 3. Locate the existing 12-pin connector of the factory harness, labeled X0396 Raven Hawkeye, running vertically along the post to the right of the power distribution cabinet.

  • Page 34: System Diagrams

    CHAPTER 5 5. Following the existing cabling and hoses, route the remainder of the cable up and over the catwalk frame to the boom center rack. 6. Connect the right and left connectors to the mating connectros on the right and left inner boom cables. 7.
  • Page 35 CHASSIS CABLE INSTALLATION FIGURE 5. Hawkeye® 2, AGCO Fendt 900 Series System Drawing Page 1 (P/N 054-2005-009 Rev. A) Chassis Cable Installation: System Diagrams...
  • Page 36 CHAPTER 5 FIGURE 6. Hawkeye® 2, AGCO Fendt 900 Series System Drawing Page 2 (P/N 054-2005-009 Rev. A) Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...
  • Page 37 CHASSIS CABLE INSTALLATION FIGURE 7. Hawkeye® 2, AGCO Fendt 900 Series System Drawing Page 3 (P/N 054-2005-009 Rev. A) Chassis Cable Installation: System Diagrams...
  • Page 38 CHAPTER 5 Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...

  • Page 39: Cable And Connector Maintenance

    C ABLE AND CONNECTOR APPENDIX A P P E N D I X A MAINTENANCE POWER AND ECU HARNESS MAINTENANCE 1. Disconnect the ECU harness connector and inspect for signs of moisture or corrosion. 2. If moisture or corrosion is detected, use Deoxit D5, brushes, and compressed air to clean and dry the connector.
  • Page 40 APPENDIX A 3. Clean contacts with a small wire brush (P/N 321-0000-477). FIGURE 2. Cleaning Contacts with a Wire Brush 4. Spray the contacts again with the deoxidizing agent to help rinse out debris. 5. Remove residue of the deoxidizing agent from the connection. CAUTION Damage to the connector seal may occur if residue is not removed from the connector.
  • Page 41 7. If not already applied, apply a single, short burst of corrosion inhibitor such as CorrosionX HD (P/N 222-0000- 020) to the NCV2 connection. Be sure the corrosion inhibitor has coated the NCV2 contacts and recessed portions of the connector. NOTE: To determine whether corrosion inhibitor has been applied, inspect for a thick liquid in the bottom of the connector as shown in the image below.
  • Page 42 APPENDIX A Hawkeye® 2 Installation Manual for AGCO Fendt RoGator 900 Series...
  • Page 43 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 45 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 46 WHAT IS NOT COVERED BY THE EXTENDED WARRANTY? Raven Industries will not assume any expense or liability for repairs outside our facility without written consent. Raven Industries is not responsible for damage to any associated equipment or products and will not be liable for loss of profit, labor, or other damages.
