Micro USB console port

Table1-15 Micro USB console port specifications
Item
Connector
Standard compliant
Baud rate
Cable type
Transmission distance
Services

GE copper port

Table1-16 GE copper port specifications
Item
Connector
Standard compliance
Interface type
Cable type
Transmission distance
Interface speed and duplex mode
NOTE:
The media dependent interface (MDI) standard is typically used on the Ethernet port of network
adapters. The media dependent interface crossover (MDI-X) standard is typically used on hubs or
LAN switches.

GE fiber port

Table1-17 GE fiber port specifications
Item
Connector type
Transceiver module type
Standard compliance
Interface speed
Specification
Micro USB
Micro USB
9600 bps (default) to 115200 bps
USB console cable
≤ 10 m (32.81 ft)
•
Connection to an ASCII terminal
•
Connection to the serial port of a local PC running the terminal
emulation program
•
CLI
Specification
RJ-45
802.3, 802.3u, and 802.3ab
MDI/MDI-X autosensing
Category 5 or higher twisted pair cable
100 m (328.08 ft)
10 Mbps, half/full-duplex
100 Mbps, half/full-duplex
1000 Mbps, full-duplex
Specification
LC
SFP
1000BASE-X
1000 Mbps
