Type 4 - Directed DIRECTECHS DS4+ Installation Manual

Type 4

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
(MUX) Door Lock: Blue/Yellow, pin 53
White 4-pin conn.
(at brake pedal switch)
1 2 3 4
(+) Brake: Green/White, pin 4
Black 12-pin conn.
(at headlight switch)
6 5 4 3 2 1 1
7 8 9 10 11 12
(-) Parking Lights:
Yellow/Black, pin 7
(+) Starter: Brown/White or
Brown/Gray, pin 3
3
14
Drivers Door Trigger: White/Violet, pin 50
CUT
60
15
Green 60-pin conn.
(MUX) Rear Door / Trunk Unlock:
(BCM/Dash fuse box)
Gray/White, pin 27
(+) 12V: Red/Dk.Green,pin 2
(+) Ignition 2 Output:
White/Black, pin 1
1
White 3-pin conn.
(at ignition switch)
BCM /Dash Fuse box
46
1
Resistor 1Κ Ω
(-) Rear Door/ Trunk Unlock Output: Red/White: 4
Resistor 1Κ Ω
Hood Pin
Siren
(-) Door Lock Interrupt (veh. side): Blue/White: 1
Resistor 1Κ Ω
(-) Door Lock Interrupt (conn. side): Blue: 3
(+) Ignition 2/Flex Relay Output: Pink/White: 4
(+) Fused (30A) Ignition 2/ Flex Relay Input: Red/White: 9
(+) Ignition 1:
Blue/Red, pin 2
(+) Accessory: Blue, pin 1
1
2 3 4
White 3-pin conn.
(at ignition switch)
B-CAN High:
OBDII Plug
Black Connector
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
MS CAN Low: Orange/Brown: 3
MS CAN High: Orange/Green: 4
(-) RAP Off Output: Brown/White: 6
(+) Brake Output: Violet/Black: 8
(-) Door Unlock Output: Dk.Blue/Black: 9
(-) Parking Light Output: Lt.Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(-) Ground Input: Blue/Red: 2
(+) 12V Input: Red: 6 &12
(-) Ground: Black: 10
(+) 12V Input: Red/Black: 2
(+) 12V Input: Red: 5
Starter Input (Key Side): Green: 6
(+) Starter Output (Car Side): Violet: 7
(+) Accessory Output: Orange: 8
(+) Ignition 1 Input/Ouput: Pink: 10
).
C-CAN High:
Blue, pin 1 Green, pin 6
1 8
9 16
C-CAN Low:
B-CAN Low:
Brown, pin 14
White, pin 9
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ CHRYSLER12
