Directed DIRECTECHS DS4+ Installation Manual page 13

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Dodge/RAM ProMaster (Gas) 2014-2017
C-CAN High Green
C-CAN Low Brown
B-CAN High Blue
B-CAN Low White
12V Red/Black
Brown/White or Brown/
Starter
Gray
Ignition 2 White/Black
Ignition 1 Blue/Red
Accessory Blue
Key Release Brown/Orange
Parking Lights Yellow/Black
Door Locks Blue/Yellow
Rear Door/Trunk Unlock Gray/White
Drivers Door Trigger White/Violet
13
Pin Polarity Location
6 Data OBDII diagnostic connector.
14 Data OBDII diagnostic connector.
1 Data OBDII diagnostic connector.
9 Data OBDII diagnostic connector.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
2 (+) Ignition switch.
1 (+) Ignition switch.
2 (+) At key cylinder
7 (-) Headlight switch.
53 MUX BCM/Dash fuse box.
27 MUX BCM/Dash fuse box.
50 (-) BCM/Dash fuse box.
Connector Information
Color
Black
Black
Black
Black
White
White
White
White
White
White
Black
Green
Green
Green
© 2017-11-15 Directed. All rights reserved.
Pins Ref.
16 A
16 A
16 A
16 A
3 B
3 B
3 B
4 C
4 C
2 D
12 E
60 F
60 F
60 F
DS4+ CHRYSLER12
