Specifications
Note The embedded modules use a supervisory circuit with a 2.93 V reset threshold. When VCC falls to
the threshold voltage, a reset pulse is issued, holding the output in active state. When power rises
above 2.93 V, the reset remains for approximately 200 ms to allow the system clock and other circuits
to stabilize.
WARNING! The rise time of the 3.3 V power supply must be between 700 µS and 140 ms
and the inrush current must be limited to less than 2 A. A rise time outside of these limits
may cause the device to malfunction and give a 3-1-3 diagnostic error.

Mechanical

Dimension
Length:
Width:
Digi Connect EM and Digi Connect Wi-EM Hardware Reference
Symbol Description
V Input High Voltage
IH
V Input Low Voltage V
IL
Symbol Description
V Output High
OH
Voltage
V Output Low
OL
Voltage
Module dimensions
Digi Connect EM
Fully populated
2.135 in
(54.229 mm)
Pin header model
1.935 in
(49.149 mm)
1.575 in
(40.005 mm)
Inputs
Min Typ Max
2 —
V +0.3
CC
-0.3 — 0.2* V
SS CC
Outputs
Min Typ Max
2.4 — 3.45
0 — 0.4
Digi Connect Wi-EM
2.287 in
(58.09 mm)
1.885 in
(47.879 mm)
Mechanical
Unit
V
V
Unit
V
V
