  • Page 1 Digi Connect EM  & Digi Connect Wi‐EM Hardware Reference  90000632_G Arrow.com. Downloaded from...
  • Page 2 Arrow.com. Arrow.com. Downloaded from Downloaded from...
  • Page 3 NetSilicon, NET+Works, NET+OS, and NET+ are trademarks of NetSilicon, Inc. All other trademarks mentioned in this document are the property of their respective owners. Information in this document is subject to change without notice and does not represent a commitment on the part of Digi International.
  • Page 4 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from...

  • Page 5: Table Of Contents

    Contents About This Guide ........................7 Scope of Reference Manual ..................... 7 Kits Contents ........................7 Related Documentation ....................9 Support Information ......................9 Chapter 1: About the Embedded Module................11 Overview ........................11 Types of Modules......................12 Connectors: Power and Serial Interface ................. 15 Connectors: Ethernet Interface..................
  • Page 6 Embedded Module LEDs....................43 Embedded Module Reset ....................44 Flash ..........................45 Appendix A: Specifications ....................47 Network Interfaces......................47 Serial Interface ....................... 48 Data Rates (bps) ......................48 Flow Control Options..................... 48 Environmental........................ 48 DC Characteristics ......................48 Mechanical ........................50 Layouts and Dimensions....................

  • Page 7: About This Guide

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Scope of Reference Manual The scope of this guide is to enable developers to integrate the Digi Connect EM or Digi Connect Wi-EM modules into other devices. Graphics illustrate the placement and dimensions of components for both the modules and the development board.
  • Page 8 Full software and hardware documentation About the Development Kit The Digi Connect EM or Digi Connect Wi-EM Development Kit is an easy-to-use and royalty-free development platform that significantly reduces traditional design risk and accelerates the overall software development process. Both kits deliver...

  • Page 9: Related Documentation

    See the NS 7520 Hardware Reference for information on the NS 7520 chip. Support Information To get help with a question or technical problem or make comments and recommendations about Digi products and documentation, use the following contact information. General...
  • Page 10 S u p p o r t I n f o r m a t i o n D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 11: Chapter 1: About The Embedded Module

    Overview Digi Connect EM and Digi Connect Wi-EM Overview The embedded modules are part of the Digi Connect family of device servers that provide simple, reliable and cost-effective network connections for serial devices. They provide fully transparent serial device connectivity over industry-standard Ethernet connections and allow both equipment manufacturers and systems integrators to network-enable products at a fraction of the time and cost required to develop a custom solution.

  • Page 12: Types Of Modules

    (included in the package) and then attach the clip to a metal surface. Input voltage for the module is 3.3 VDC. Types of Modules The following describes the three types of Digi Connect EM and three types of Digi Connect Wi-EM modules: Choosing a Module for Your Product Although any of the embedded modules can be designed into your product, a JTAG header would typically be used only for debugging during the development process.
  • Page 13 A b o u t t h e E m b e d d e d M o d u l e DC-EM-02T-ST Digi Connect EM Modules Model Description Figure Used for development purposes only JTAG interface DC-EM-02T-JT Pin headers for Ethernet and LED functionality.
  • Page 14 (P2) is always used for transmit and receive.The left antenna is receive only. The antenna will choose the best signal (pin vs. socket). The Digi Connect Wi-EM always has two antenna connectors but using the second antenna is optional.

  • Page 15: Connectors: Power And Serial Interface

    Connectors: Power and Serial Interface This single 12-pin, serial interface port (labeled P4 for Digi Connect EM and P5 for Digi Connect Wi-EM) supports 2 TTL serial interfaces, data rates up to 230 Kbps and full- modem control (on port 1). See the figure for help locating pins and the table for pin assignments.

  • Page 16: Connectors: Ethernet Interface

    Data) Data) For a diagram of the Digi Connect Ethernet pin header location and assignments see "Digi Connect EM Pin Header Locations (Top view)" on page 20. D i g i C o n n e c t E M & D i g i C o n n e c t W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 17: Connectors: Antenna

    A b o u t t h e E m b e d d e d M o d u l e Connectors: Antenna The Digi Connect Wi-EM has 2 RP-SMA antenna connectors labeled P2 and P3. Wi-EM Antenna Connectors...

  • Page 18: Reset Switch

    R e s e t S w i t c h Reset Switch The behavior of the reset switch is determined by software, which means that it has a predefined behavior in the integration kit. In the development kit, its behavior is determined by your implementation.
  • Page 19 (red) 4 (-) Blinking 1-5-1 - configuration has been returned to factory defaults. programmable Note: If other blinking patterns occur, contact Digi Technical Support. Bottom This LED is 6 (+) right Blinking - network data is transmitted or received...
  • Page 20 M o d u l e L E D s Digi Connect EM Pin Header Locations (Top view) pin 12 Ethernet pin header pin 1 pin header Ethernet pin header, P13 The pins in the Ethernet header are configured as shown:...
  • Page 21 A b o u t t h e E m b e d d e d M o d u l e Digi Connect Wi-EM Pin Header Locations (Top view) LED pin header LED pins and pin header configuration are described in the "LED Behaviors" table on page 19.
  • Page 22 M o d u l e L E D s D i g i C o n n e c t E M & D i g i C o n n e c t W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 23: Chapter 2: About The Development Board

    About the Development Board Overview This chapter provides information on the development board, a hardware platform from which you can determine how to integrate the embedded module into your design. For additional information, see the schematic and mechanical drawings. If you have installed the development kit or integration kit, you can access the schematic from the Start menu.
  • Page 24 SPI connector Status LEDs Reset switch CR19 SPI jumper block Main Digi Connect EM 3.3V LED connector Ethernet Ethernet power LED connector Power jack D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 25: Ports

    A b o u t t h e D e v e l o p m e n t B o a r d Ports The development board provides the following ports: Serial Port 1 (P1) and Serial Port 2 (P2) Ethernet Port (P12) GPIO Port (P3) Serial Port 1 (P1) and Serial Port 2 (P2)
  • Page 26 P o r t s Ethernet Port (P12) The Ethernet port of the Digi Connect EM embedded module (labeled P12) is an 8-pin RJ-45 jack meeting the requirements of ISO 8877 for 10/100Base-T. When two descriptions are shown for a pin, the second is for use with 802.3af powered Ethernet.

  • Page 27: Connectors And Blocks

    A b o u t t h e D e v e l o p m e n t B o a r d GPIO Port Pin Assignments Signal Name GPIO-9 GPIO-8 GPIO-7 GPIO-6 GPIO-5 GPIO-4 GPIO-3 GPIO-2 GPIO-1 Connectors and Blocks The development board provides the following connectors and blocks: JTAG Debugger Connector (P4) SPI Connector (P11) and SPI Jumper Block...
  • Page 28 C o n n e c t o r s a n d B l o c k s JTAG Debugger Connector Pin Orientation JTAG Debugger Connector Pin Assignments Signal VCC+ /TRST /SRST VCC+ SPI Connector (P11) This connector is used for a Serial Peripheral Interface (SPI) connection. When enabled, signals are disconnected from serial port 1 and GPIO connectors.
  • Page 29 A b o u t t h e D e v e l o p m e n t B o a r d SPI Pin Assignments Signal SPI-EN SPI-CLK SPI-TX SPI-RX connected connected SPI Jumper Block The SPI jumper block determines whether the SPI connector is connected or not. If SPI is off (the default), serial and GPIO signals are routed to switch banks 1 through 4.
  • Page 30 C o n n e c t o r s a n d B l o c k s Logic Analyzer Header Pin Orientation Pin 1 Pin 2 Pin 20 Pin 19 Logic Analyzer Header Pin Assignments Signal 1 - 8 Not connected /RST Not connected...

  • Page 31: Power Jack (P17)

    A b o u t t h e D e v e l o p m e n t B o a r d Main Connector (P8) This 12-pin connector is used to interface with the embedded module. See the following figure for pin orientation.

  • Page 32: Switches

    S w i t c h e s The following figure schematically represents the polarity of the power jack Power Jack Polarity Schematic . Ground +9 to +30 VDC Switches The development board provides the following switches: Reset Switch (SW5) Serial/GPIO Switch Bank 3 (SW3) and Switch Bank 4 (SW4) GPIO Switch Bank 1 (SW1) and 2 (SW2) Reset Switch (SW5)
  • Page 33 A b o u t t h e D e v e l o p m e n t B o a r d Serial/GPIO Switch Bank 3 (SW3) and Switch Bank 4 (SW4) Each switch bank holds five slide switches that enable either serial or GPIO signaling between the development board and the module.

  • Page 34: Development Board Leds

    D e v e l o p m e n t B o a r d L E D s GPIO Switch Bank 1 (SW1) and 2 (SW2) GPIO Switch Bank 1 and Switch Bank 2, labeled SW1 and SW2, are two sets of five slide switches that set GPIO inputs to logic levels of high (switch to left) or low (switch to right).
  • Page 35 A b o u t t h e D e v e l o p m e n t B o a r d LED Descriptions Board Description Color or State Indication Label Yellow Active Green Inactive Not connected or signal not being driven Flickering Serial activity...

  • Page 36: Test Points

    T e s t P o i n t s LED Descriptions Board Description Color or State Indication Label Ethernet power present from external powered Ethernet connector CR21 EPWR, Powered Ethernet Enabled (Ethernet hub or switch) No powered Ethernet voltage Test Points The development board provides 25 test points that can be identified by board label or test point number.
  • Page 37 A b o u t t h e D e v e l o p m e n t B o a r d Test Point Descriptions Test Board Description Point Label TP11 IO-1 GPIO-1 TP12 IO-2 GPIO-2 TP13 IO-3 GPIO-3 TP14 IO-4...
  • Page 38 T e s t P o i n t s D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 39: Chapter 3: Programming Considerations

    Programming Considerations This chapter addresses the embedded modules programming considerations. This chapter applies only to development kit customers. Note GPIO General Information The NS7520 processor supports 16 general purpose I/O (GPIO) lines, some of which are reserved for specific functions and some of which can be customized. These GPIO lines fall into three categories: Those labeled “Reserved”...
  • Page 40 G P I O GPIO Registers Two registers, PORTA and PORTC, govern the 16 GPIO pins. Each is responsible for eight GPIO pins, and each pin has four bits that completely describe its behavior. The four bits that describe the GPIO behavior are its mode (CMODE), direction (CDIR), special function (CSF--only applicable to PORTC), and data value.
  • Page 41 P r o g r a m m i n g C o n s i d e r a t i o n s GPIO Pin Use GPIO Pin Use Register External Name Category Description Interface Used for port 1 serial transmit but can be reassigned as GPIO input TXD/ Pin 4 on the...
  • Page 42 G P I O GPIO Pin Use Register External Name Category Description Interface Used for the port1 serial DSR signal but can be reassigned as DSR/ Pin 9 on the PORTA2 Allocated GPIO input or output. If used GPIO-3 main header with the development board, this pin maps to GPIO-3.

  • Page 43: Embedded Module Leds

    P r o g r a m m i n g C o n s i d e r a t i o n s GPIO Pin Use Register External Name Category Description Interface Used as the NET+OS green LED Connected to but can be reassigned as a general the green...

  • Page 44: Embedded Module Reset

    E m b e d d e d M o d u l e R e s e t For information on LED control, see the NET+Works BSP Porting Guide. About Embedded Module LEDs Embedded Module LED Description Description Green This LED is wired to the network hardware and provides an indication of link status.

  • Page 45: Flash

    P r o g r a m m i n g C o n s i d e r a t i o n s Reset Characteristics Characteristic Specification Delay 200 milliseconds (typical) Threshold 2.93 V Minimum Hold Time 1 microsecond pulse Soft Reset NET+OS provides an internal facility to enact a soft reset, but it is the responsibility of a specific implementation to choose a reasonable trigger to invoke it.
  • Page 46 F l a s h D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 47: Appendix A: Specifications

    2Mbps: -89 dBm – 5.5Mbps: -87 dBm – 11Mbps: -82 dBm Antenna connector: 2 x RP-SMA Digi Connect EM Embedded Module Standard: IEEE 802.3 Data rate: 10/100 Mbps (auto-sensing) Mode: Full or half duplex (auto-sensing) Connector: RJ-45 or pin header Arrow.com.

  • Page 48: Serial Interface

    Data Rates (bps) 50, 110, 134, 150, 200, 300, 600, 1200, 2400, 3600, 4800, 9600, 19200, 38400, 57600, 115200, 230400 Flow Control Options RTS/CTS, XON/XOFF, None Environmental Digi Connect EM Digi Connect Wi-EM F to 185 F to 185 Ambient Temperature (-40...
  • Page 49 S p e c i f i c a t i o n s Operating Conditions Symbol Description Unit Supply Voltage 3.14 3.45 Power Supply Ripple mVpp Digi Connect Supply Current — — Digi Connect Wi-EM Input Current as “0” μA —...

  • Page 50: Mechanical

    140ms and the inrush current must be limited to less than 2 A. A rise time outside of these limits may cause the device to malfunction and give a 3-1-3 diagnostic error. Mechanical Module Dimensions Dimension Digi Connect EM Digi Connect Wi-EM Fully populated 2.135 in (54.229 mm) 2.287 in Length: (58.09 mm)

  • Page 51: Layouts And Dimensions

    Layouts and Dimensions The following dimensions and layouts are for both the Digi Connect Wi-EM and Digi Connect EM. It is strongly recommended that you consider using the Digi Connect Wi-EM footprint for future flexibility. All dimensions are in inches. We recommend that you use the Recommended...
  • Page 52 L a y o u t s a n d D i m e n s i o n s Digi Connect Wi-EM (w/LED Array) D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 53 S p e c i f i c a t i o n s Front Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 54 L a y o u t s a n d D i m e n s i o n s Bottom D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 55 S p e c i f i c a t i o n s Digi Connect Wi-EM (w/LED Pin Headers) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 56 L a y o u t s a n d D i m e n s i o n s Front D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 57 S p e c i f i c a t i o n s Bottom Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 58 L a y o u t s a n d D i m e n s i o n s Digi Connect EM (w/RJ-45 and LED Array) 1.575 1.935 .494 .107 .200 .697 .874 1.474 D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 59 S p e c i f i c a t i o n s Front Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 60 L a y o u t s a n d D i m e n s i o n s Bottom .100 .955 .739 .405 .710 1.835 .100 (TYP) .100 Ø.125 TYP 1.475 D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 61 S p e c i f i c a t i o n s Digi Connect EM (with Ethernet and LED Pin Headers) 1.475 Ø.125 TYP .100 1.935 1.835 .405 .739 1.575 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 62 L a y o u t s a n d D i m e n s i o n s Front D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 63: Recommended Pcb Layouts

    The following graphics are the recommended PCB layouts for the Digi Connect Wi-EM and Digi Connect EM (both populated and unpopulated versions). It is recommended that you use the Digi Connect Wi-EM PCB layout for future flexibility since it is slightly wider than the Digi Connect EM.
  • Page 64 R e c o m m e n d e d P C B L a y o u t s Digi Connect Wi-EM (w/LED Array) D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 65 S p e c i f i c a t i o n s Digi Connect Wi-EM (w/LED Pin Headers) Pin 1 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 66 R e c o m m e n d e d P C B L a y o u t s Digi Connect EM (w/RJ-45 and LED Array) RECOMMENDED PCB LAYOUT TOL. ±.005 1.575 .050 .125 Ø.040 MIN .100 .050 1.935...
  • Page 67 S p e c i f i c a t i o n s Digi Connect EM (with Ethernet and LED Pin Headers) RECOMMENDED PCB LAYOUT 1.575 TOL. ±.005 .100 .100 Ø.040 MIN Pin 1 1.935 .710 .4615 .100 .135 .1805...

  • Page 68: Antenna Information

    A n t e n n a I n f o r m a t i o n Antenna Information Antenna Strength The following diagram demonstrates the strength of the signal received by the antenna on both a horizontal and vertical plane. The diagram shows the magnetic field when the antenna is in a vertical position.
  • Page 69 S p e c i f i c a t i o n s Radiation Patterns for PCB Mount Antenna Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 70 DC-ANT-24SM * The PCB mount antenna requires a RP-SMA to U.FL adapter cable(s), or a customized version of the Digi Connect Wi-EM module with an integrated U.FL cable (single antenna). Please contact Digi sales for specific availability information. Any antenna matching the in-band and out-of-band signal patterns and strengths of the antenna, whose characteristics are given in the Antenna Description table and the Radiation pattern graphic, may be used with the Digi Connect Wi-EM.
  • Page 71 S p e c i f i c a t i o n s Dipole Antenna Dimensions Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 72 A n t e n n a I n f o r m a t i o n Desktop Antenna Dimensions D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.
  • Page 73 S p e c i f i c a t i o n s PCB Mount Antenna Dimensions Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 74: Rf Exposure Statement

    R F E x p o s u r e S t a t e m e n t RF Exposure Statement The Digi Connect Wi-EM module complies with the RF exposure limits for humans as called out in RSS-102. It is exempt from RF evaluation based on its operating frequency of 2.4 GHz, and effective radiated power less than the 3 watt requirement for a mobile device...
  • Page 75 S p e c i f i c a t i o n s Do not touch uninsulated ethernet wiring if lightning is likely! Do not touch or move the antenna(s) while the unit is transmitting or receiving. Do not hold any component containing a radio such that the antenna is very close to or touching any exposed parts of the body, especially the face or eyes, while transmitting.
  • Page 76 S a f e t y S t a t e m e n t s D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com.

  • Page 77: Appendix B: Certifications

    FCC Part 15 Class B Radio Frequency Interference (RFI)(FCC 15.105) The Digi Connect EM and Digi Connect Wi-EM embedded modules have been tested and found to comply with the limits for Class B digital devices pursuant to Part 15 Subpart B, of the FCC Rules.

  • Page 78: Industry Canada

    FCC ID / IC ID. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: MCQ-50M879” / IC: 1846A-50M879”. Modifications (FCC 15.21) Changes or modifications to this equipment not expressly approved by Digi may void the user's authority to operate this equipment. Industry Canada...

  • Page 79: Declaration Of Conformity

    The products listed above have been tested at an External Test Laboratory certified per FCC rules and has been found to meet the FCC, Part 15, Class B, Emission Limits. Documentation is on file and available from the Digi International Homologation Department.

  • Page 80: International Emc Standards

    I n t e r n a t i o n a l E M C S t a n d a r d s International EMC Standards The Digi Connect EM and Digi Connect Wi-EM meet the following standards: Digi Connect...

  • Page 81: Appendix C: Sample Application: Ttl Signals To Eia-232

    Sample Application: TTL Signals to EIA-232 The following schematic is an example of how to convert the module’s TTL signals to EIA-232. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 82 D i g i C o n n e c t E M & W i - E M H a r d w a r e R e f e r e n c e Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 83: Revision G

    Change Log The following changes have been made since the last revision of this document. Revision G Added tolerances to dimension drawings Updated Tyco Antenna Specifications Revision F Ethernet Pinouts added Updated Antenna specification Addressed Vantive 16410 hardware issues Added product weights Updated UL labeling description Revision E Added Japan certification...
  • Page 84 R e v i s i o n E Improve dipole antenna drawing Reformatted tables for easier reading Added antenna extension cord information Added more receive sensitivity information Added reset hold times Added VCC *absolute max* ratings Added power rise time infomation Combined PCB layouts with improvements D i g i C o n n e c t E M &...
  • Page 85 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 86 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
