Spi Jumper Block - Digi Connect EM DC-EM02T-JT Hardware Reference Manual

About the development board
SPI Connector Pin Orientation
Pin
1
Signal SPI-EN GND SPI-CLK GND SPI-TX GND SPI-RX GND

SPI jumper block

The SPI jumper block determines whether the SPI connector is connected or not. If SPI is off (the
default), serial and GPIO signals are routed to switch banks 1 through 4. (See
SPI jumper block.) If SPI is on, SPI signals are routed to the SPI connector (P11).
The following figures demonstrate how to set the SPI jumper block
Digi Connect EM and Digi Connect Wi-EM Hardware Reference
SPI pin assignments
Pin
Pin Pin Pin
2 3 4 5
Pin Pin
Pin Pin
6 7 8
Not
connected
SPI jumper block
Connectors and blocks
Pin
9 10
Not
connected
and
21
