Table 7: Model Types and Options for Enfinity Single Stage Compressor
Number of
Model Number
Compressors
1 Single
1
2 Single
3 Single
4 Single
5 Single
6 Single
7 Single
8 Single
9 Single
10 Single
11 Single
12 Single
13 Single
14 Single
15 Single
16 Single
17 Dual
18 Dual
Except for the Enfinity single-compressor WSHP with no other options selected, all Enfinity models require both the unit controller and I/O expansion module.
1
An "X" means that option is available for the corresponding WSHP model.
2
SmartSource Single and Two Stage Compressor (Series2) and SmartSource
Compact
Table 8: Unit Controller Configuration Jumpers for SmartSource Single and Two Stage Compressor (Series2) and
SmartSource Compact
Unit Controller Option
Normal / Test Mode
Fan Operation
Loop Fluid
Freeze Fault Protection
Room Sensor Setpoint Adjust Range
Thermostat / Room Sensor
Compressor Heating Source
I/O Expansion Module
www.DaikinApplied.com
1 Speed Fan 2 Speed Fan
X —
X —
X —
X —
X —
X —
— X
X
—
X
—
— X
— X
— X
— —
— —
— —
— —
X —
X —
Hardware Jumpers
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
29
Troubleshooting Guide and FAQ
3 Speed Fan HGR Dehumid
— —
— X
— —
— —
— X
— X
— —
X
—
— —
— —
— X
— X
X —
X —
X X
X X
— —
— X
Setting Description
JP1 = Open Normal Operation
JP1 = Shorted Service / Test Mode
JP2 = Open Continuous Fan Operation (ON)
JP2 = Shorted Cycling Fan Operation (AUTO)
JP3 = Open Water Loop Fluid
JP3 = Shorted Glycol Loop Fluid
JP4 = Open LWT Freeze Fault Protection is Disabled
JP4 = Shorted LWT Freeze Fault Protection is Enabled
JP5 = Open Short Range: -5 to +5 ºF (-2.78 to +2.78 ºC)
JP5 = Shorted Long Range: 55 to 95 ºF (12.78 to 35 ºC)
JP6 = Open Thermostat Control
JP6 = Shorted Room Sensor Control
JP7 = Open Allow Compressor Heating Mode Operation
JP7 = Shorted Disable Compressor Heating Mode Operation
JP8 = Open I/O Expansion Module is Not Present
JP8 = Shorted I/O Expansion Module is Required
OM 1085-6 • MICROTECH III CONTROLLER
Supplemental Boilerless
Electric Heat Electric Heat
— —
— —
X —
— X
X —
— X
— —
— —
X
—
— X
X —
— X
X —
— X
X —
— X
— —
— —
