Texas Instruments ADS867 Series Manual page 79

DBT0038A
38 X (0.3)
38 X (0.5)
SOLDER MASK
OPENING
EXPOSED METAL
NON-SOLDER MASK
NOTES: (continued)
6. Publication IPC-7351 may have alternate designs.
7. Solder mask tolerances between and around signal pads can vary based on board fabrication site.
38 X (1.5)
1
19
LAND PATTERN EXAMPLE
EXPOSED METAL SHOWN
METAL
0.05 MAX
ALL AROUND
DEFINED
(PREFERRED)
SOLDER MASK DETAILS
EXAMPLE BOARD LAYOUT
TSSOP - 1.2 mm max height
SYMM
(5.8)
SCALE: 10X
METAL UNDER
SOLDER MASK
15.000
www.ti.com
SMALL OUTLINE PACKAGE
(R0.05) TYP
38
SYMM
20
SOLDER MASK
OPENING
EXPOSED METAL
0.05 MIN
ALL AROUND
SOLDER MASK
DEFINED
4220221/A 05/2020
