8.5.2.3.3 Range Select Registers (addresses 05h-0Ch)
Address 05h corresponds to channel 0, address 06h corresponds to channel 1, address 07h corresponds to
channel 2, address 08h corresponds to channel 3, address 09h corresponds to channel 4, address 0Ah
corresponds to channel 5, address 0Bh corresponds to channel 6, and address 0Ch corresponds to channel 7.
These registers allow the selection of input ranges for all individual channels (n = 0 to 3 for the ADS8674 and n =
0 to 7 for the ADS8678). The default value for these registers is 00h.
7 6
0 0
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 15. Channel n Input Range Registers Field Descriptions
Bit Field
7-4 0
3-0 Range_CHn[3:0]
Copyright © 2015, Texas Instruments Incorporated
Figure 112. Channel n Input Range Registers
5 4
0 0
R-0h R-0h
Type Reset Description
R 0h Must always be set to 0
R/W 0h Input range selection bits for channel n (n = 0 to 3 for the ADS8674 and
n = 0 to 7 for the ADS8678).
0000 = Input range is set to ±2.5 x V
0001 = Input range is set to ±1.25 x V
0010 = Input range is set to ±0.625 x V
0011 = Input range is set to ±0.3125 x V
1011 = Input range is set to ±0.15625 x V
0101 = Input range is set to 0 to 2.5 x V
0110 = Input range is set to 0 to 1.25 x V
0111 = Input range is set to 0 to 0.625 x V
1111 = Input range is set to 0 to 0.3125 x V
Product Folder Links:
3 2
Range_CHn[3:0]
R/W-0h
REF
REF
Submit Documentation Feedback
ADS8674 ADS8678
ADS8674, ADS8678
SBAS627 – JULY 2015
1 0
REF
REF
REF
REF
REF
REF
REF
