6.4 CALIB. HIGH / 100%
3.3.8

EXPLANATION OF SETUP-MENU 7 - OTHERS

SETUP FUNCTIONS AND VARIABLES
7 OTHERS
7.1 TYPE / MODEL
7.2 SOFTWARE VERSION
7.3 SERIAL NO.
7.4 PASS CODE
7.5 TAGNUMBER
With this setting it is possible to calibrate the input value for 100% as
the signal from the sensor might not be exact 100% at maximum level
(offset + span). This function will measure the real output value at
maximum level.
Be very sure that the offered signal is correct before calibration is
executed, as this has major influence on the accuracy of the system
After pressing PROG, three settings can be selected:
▪
CALIBRATE: with this setting, the input will be calibrated with the
actual "100%" value. After pressing enter, CAL SET will be
displayed as soon as the calibration is completed. From that
moment, the analog value must be less than the calibrated value
for reliable measurements.
▪
DEFAULT: with this setting, the factory value is re-installed.
▪
CAL SET: to select the last calibrated value.
For support and maintenance it is important to have information about
the characteristics of the F073-T.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
All SETUP-values can be pass code protected.
This protection is disabled with value 0000 (zero).
Up to and including 4 digits can be programmed, for example 1234.
For identification of the F073-T and communication purposes, a
unique tag number of maximum 7 digits can be entered.
