CONFIGURATION SETTINGS

All settings of the F073-T can be set via the control panel.
The following paragraphs give a detailed description of each setting.
3.3.1

OVERVIEW FUNCTIONS SETUP LEVEL

SETUP FUNCTIONS AND VARIABLES
1 LEVEL
1.1 UNIT
1.2 DECIMALS
1.3 SPAN
1.4 OFFSET
2

HEIGHT

2.1 UNIT
2.2 DECIMALS
2.3 SPAN
2.4 OFFSET
3 ALARM
3.1 EMPTY
3.2 ALARM LOW
3.3 ALARM HIGH
3.4 DELAY ALARM LOW
3.5 DELAY ALARM HIGH
3.6 ALARM OUTPUT
4 DISPLAY
4.1 UNDER
4.2 SET ALARM
4.3 BACKLIGHT (optional)
4.4 BACKLIGHT ALARM
4.5 BL. BRIGHTNESS
5 POWER MANAGEMENT
5.1 LCD UPDATE
5.2 BATTERY MODE
6 SENSOR
6.1 FILTER
6.2 CUT-OFF
6.3 CALIBRATE LOW
6.4 CALIBRATE HIGH
7 OTHERS
7.1 TYPE / MODEL
7.2 SOFTWARE VERSION
7.3 SERIAL NO.
7.4 PASS CODE
7.5 TAGNUMBER
L - m3 - kg - lb - GAL - USGAL - bbl - no unit
0 - 1 - 2 - 3 (Ref: displayed value)
0.001 to 999,999 unit
-999,999 to +999,999 unit
mm - cm - m - mtr - inch - ft - mmwk - mmwc - cmwk - cmwc - mwk -
mwc - inwc - ftwc - mbar - bar - psi - no unit.
0 - 1 - 2 (Ref: displayed value)
0.01 to 999,999 unit
-999,999 to +999,999 unit
default - no relays - ignore
-999,999 to +999,999 unit
-999,999 to +999,999 unit
0.1 - 999.9 seconds
0.1 - 999.9 seconds
high - low – hi_lo - off
height - percentage - off
operator - setup
off - on
off - on - flash
1 - 5
fast - 1 sec - 3 sec - 15 sec - 30 sec - off
operational - shelf
00 - 99
0.0 - 99.9%
default - calibrate - calibrate set
default - calibrate - calibrate set
F073-T
03.03.xx
xxxxxxx
0000 - 9999
0000000 - 9999999
