FastPak
Control Panel
Retrofit
 American Standard Inc. 2001
Operation
Maintenance
Library
Product Section
Product
Model
Literature Type
Sequence
Date
File No.
Supersedes
Classic Black
Panel
Since The Trane Company has a policy of continuous product and product data improvement, it reserves the right to
change design and specifications without notice. Only qualified technicians should perform the installation and servicing of
equipment referred to in this publication.
Commercial Aftermarket Products
SV-CAP-CTV-CVRC-M-1D-0501
Double Door
Pneumatic Panel
CVRC-M-1D
Service Literature
CenTraVac
CVRC
Operation, Maintenance
1D
June 2001
CVRC-M-1C-101
Single Door
Pneumatic Panel
