Remote Configuration; Figure 8. Remote Configuration - ADTRAN Smart 16e Shelf User Manual

Remote Configuration

Remote Configuration
The Smart 16e Shelf and any rackmount units in the shelf can be configured remotely through the
port using a modem. See Figure 8. Follow these steps to set up this application.
DTE/DCE EIA 232
1. Configure the modem as follows:
• Display Result Code
• Echo Off
• Result Code Displayed as Words (verbose form)
• Normal DTR
• Normal DCD
• Auto Answer On
2. At the remote site, configure the EIA232 DIR option as DTE.
3. Make sure the shelf baud rate is not configured above 19.2 kbps.
4. Set the data format as follows: word length = 8 bits, parity = none, stop bit = 1.
SMART 16e
AC
POWER I/F
L
A
N
10 BASE T
D
T
E
/
D
C
E
E
I
A
2
3
2
ALARM
NO
#1
COM
NO
#2
COM
F1
5A
250V
3AG
F2
115VAC/60 HZ
2.5 AMP
32
MODEM
MODEM

Figure 8. Remote Configuration
