If a key is pressed without using Shift, the numbered item becomes active instead of the alpha item. If this
happens, repeat the correct procedure.
Quick
During most operations, the Quick key returns the display to the Main menu. During a test, this key returns
to the top of the menu.
T
EST
Cancel
The Cancel key stops the current activity and returns to the previous menu. Press Cancel until the desired
menu level is reached.
Up and Down Arrows
These arrows scroll through the submenu items available in the current menu. Submenu items appear two
at a time. When scrolled, they continuously appear from beginning to end in a forward (down arrow) or
reverse (up arrow) pattern
3. NETWORK MANAGER OPERATION USING SLIP, ASYNC PPP, OR ETHERNET
INTERFACE
Before SLIP, async PPP, or Ethernet communication can be established with a network manager, some
initial network settings must be configured using a local VT100 terminal or DATAMATE attached to the
EIA-232 port of the Smart 16e controller card.
Obtain information such as the internet protocol (IP) address, subnet mask, gateway IP
address, and trap host IP address from the network administrator.
The Ethernet LAN interface in the Smart 16e controller card has the network media access control (MAC)
address as displayed in hexidecimal byte notation. The IP address, subnet mask, gateway, and trap host
systems are entered using dotted decimal notation.
The subnet mask is the filter used for subnetwork addressing. The default value is a typical Class C subnet
mask value (255.255.255.0).
The SNMP community names are used in SNMP GET, SET, and trap messages for authentication.
The trap host IP address identifies where the network manager system receives trap messages from the
Smart 16e Shelf.
