APPENDIX A
10/100BaseT Ethernet Pinout
Table A-1 shows the pinout for the LAN port on the 10/100BaseT Ethernet card.
Table A-1. 10/100BaseT Connector Pinout
Pin
Name
1
TX1
2
TX2
3
RX1
4, 5
-
6
RX2
7, 8
-
Alarm Connection Pinout
Table A-2 shows the pinout for the alarm connection.
Table A-2. Alarm Connector Pinout
Pin
Description
1
COM #2
2
NO #2
3
COM #1
4
NO #1
64202023L5-1B
PINOUTS
Description
Transmit Positive
Transmit Negative
Receive Positive
Not Used
Receive Negative
Not Used
© 2004 ADTRAN, Inc.
51
