Installation into Cabinet or Rack
Power Up
The shelf and installed units are internally powered by an AC or DC supply. An optional second power
supply can be used for redundant protection.
The dual input power shelves 4202023L6 (AC) and 4202023L8 (DC) provide the user greater redundancy
by allowing the shelf to be powered by two separate AC (or DC) circuits so that service will not be
interrupted upon a single circuit breaker fault. Shelf power inputs can be both AC or both DC, but they
cannot be mixed.
2.
INSTALLATION INTO CABINET OR RACK
The set of brackets supplied with the Smart 16e Shelf can be used for either 19" or 23" applications. For
19" applications, the longer side of the bracket should be flush with the side of the chassis. For 23"
applications, the short side of the bracket should be flush with the side of the chassis.
There are two sets of mounting holes for the brackets on the left and right sides of the Smart 16e Shelf. One
set positions the front of the Smart 16e Shelf in line with the front of the rack. The other set extends the
front of the Smart 16e Shelf beyond the front of the rack.
3.
INSTALLATION OF POWER SUPPLIES
Second generation dual power interface cards shipped with this shelf are ONLY for use in
second generation Smart 16/16e Shelves. Shock hazard may result from accidentally
plugging a second generation dual power interface card into a first generation
Smart 16/16e Shelf (P/N 4200023L3 through 4200023L6).
Affected power interface cards: Smart 16 Dual Input AC1202035L2
The second generation dual power interface cards are, however, completely safe
when properly installed in a second generation Smart 16/16e Shelf (P/N 4202023L1
through 4202023L8).
In accordance with UL 60950, the following safety guidelines must be met for installation of the
Smart 16/16e AC power supply (P/N 1200048L3 or 1202048L1):
•
To be installed in a Restricted Access Location.
•
Input Voltage Rating: 120 VAC, +6%, -10%.
•
Use appropriately sized copper conductors only.
•
Care should be exercised not to upset the stability of the equipment rack when installing this product.
•
The proper means of the earth connection shall be included in the installation instructions.
22
Smart 16 Dual Input DC1202044L2
Smart 16e Dual Input AC1202163L2
Smart 16e Dual Input DC1202164L2
© 2004 ADTRAN, Inc.
Smart 16e Shelf User Manual
64202023L5-1B
