Installation of Controller Card
Second generation dual power interface cards shipped with this shelf are ONLY for use in
second generation Smart 16/16e Shelves. Shock hazard may result from accidentally
plugging a second generation dual power interface card into a first generation
Smart 16/16e Shelf (P/N 4200023L3 through 4200023L6).
Affected power interface cards: Smart 16 Dual Input AC1202035L2
The second generation dual power interface cards are, however, completely safe
when properly installed in a second generation Smart 16/16e Shelf (P/N 4202023L1
through 4202023L8).
30
8-pin modular jack
used for Ethernet
10BaseT connection
Fuse for left power supply

Figure 6. Dual DC Version (4202023L8 Shelf)

© 2004 ADTRAN, Inc.
SMART 16e
DUAL DC
POWER I/F
L
A
N
10 BASE T
EIA-232 (DB-9) connector
interface for asynchronous
D
T
ASCII terminal VT100
E
/
D (local and remote configuration)
C
E
E
I
A
2
3
2
Removable terminal strip for external
alarm circuits or other devices
ALARM
NO
#1
COM
NO
#2
COM
F1
Fuse for right power supply
5A
250V
3AG
F2
External DC Power Supply Specs:
Shelf Input=48 VDC, 4 A
48V ,4A
-
#1
+
-
#2
+
Smart 16 Dual Input DC1202044L2
Smart 16e Dual Input AC1202163L2
Smart 16e Dual Input DC1202164L2
Smart 16e Shelf User Manual
64202023L5-1B
