UNPACK, INSPECT, POWER UP

Receiving Inspection

Carefully inspect the Smart 16e Shelf for any shipping damages. If damage is suspected, file a claim
immediately with the carrier and contact ADTRAN Customer Service (see front pages of this manual for
contact information). If possible, keep the original shipping container for use in shipping the Smart 16e
Shelf for repair or for verification of damage during shipment.

ADTRAN Shipments Include

The following items are included in ADTRAN shipments of the Smart 16e Shelf:
• Smart 16e chassis
• Controller card
• Power supply (AC or DC) (two included in 4202023L6 and L8)
• Blank power faceplate (only in 4202023L5 and L7)
• Rear panel segment for power input and controller operation
• Mounting brackets for shelf

Customer Provides

The customer must supply the following items:
• A PC capable of emulating VT100 for configuring devices installed in the Smart 16e Shelf
• An EIA-232, DB-9 cable for connection to the VT100 interface
• Optionally, a DATAMATE (part number 1200045L1) can be used for most shelf configuration
• For SNMP access, a cable for connection to either the controller card's EIA-232 connector (for SLIP
or PPP async protocol) or the card's 10/100BaseT interface (for Ethernet protocol)
The VT100 interface is required for setting up the initial network settings for SLIP, async
PPP, or Ethernet communications.
