Outputs Wiring; Figure 4: Door Lock - Failed Close - Rosslare AC-215IP Installation Manual

Single and double door access control unit

Table of Contents

AC-215IP Panel Setup

3.3

Outputs Wiring

Figure 4 and Figure 5 illustrate wiring for two main types of 12 VDC electrical

release mechanisms. Other electrical devices can be switched using the voltage

free relay contacts.

Figure 4: Door Lock – Failed Close

AC-215IP Hardware Installation Manual
