3. 각 부분 명칭 및 기능
LVM-171S : 전면
LVM-171S : 후면
AC IN
POWER S/W
DC IN
CVBS1/Y/G/S-Y IN
CVBS2/Pb/B IN
CVBS3/PR/R/S-C IN
HDMI IN
SDI-A IN
SDI-B IN
POWER
SOURCE
SCAN
ASPECT
MARKER
FUNCTION/
FUNCTION SELECT
MENU/EXIT
KNOB(UP/DOWN/ENTER)
USB(Firmware Update)
AUDIO OUT
REMOTE
RS-422 IN
RS-422 OUT
CVBS1/Y/G/S-Y OUT
CVBS2/Pb/B OU T
CVBS3/Pr/R/S-C OUT
DVI-I(w/HDCP) IN
SDI-A OUT
SDI-B OUT
LAN
AUDIO-IN
Multi Format LCD Monitor 7
