7.지원 해상도
SDI / HDMI 지원 해상도
Input Signal
Interfaces
SD SDI
single link
Input Signal
Interfaces
3G-SDI (A/B)
single link
Input Signal
Interfaces
HD SDI
single link
Input Signal
Interfaces
HDMI
single link
720x487
(59.94i)
720x576
(50i)
1920x1080 (60p/59.94p/50p)
1920x1080 (30/29.97/25/24/23.98/
30sF/29.97sF/25sF/24sF/23.98sF)
1920x1080
(23.98/24/25/29.97/30p)
(50/59.94/60I)
(24/25/29.97/30psf)
1280x720
(50/59.94/60P)
1080p
(60/59.94/50/30/29.97/25/24/23.98)
1080i
(60/59.94/50)
720p (50/59.94/60p)
480i(60) / 576i(50)
480p(60) / 576p(50)
Signal Foramt (SD SDI)
YCbCr 4:2:2 10bit
Signal Format (3G SDI)
YCbCr 4:2:2 10bit
RGB 4:4:4 10bit / 12bit
YCbCr 4:4:4 10bit / 12bit
Signal Format (HD SDI)
YCbCr 4:2:2 10bit
Signal Format (HDMI)
RGB 4:4:4 8bit / 10bit / 12bit
YCbCr 4:4:4 8bit / 10bit / 12bit
YCbCr 4:2:2 8bit / 10bit / 12bit
