  • Page 1: Lcd Monitors

    Multi Format Broadcast LCD Monitors LVM-420A LVM-460A LVM-550A...

  • Page 2: Table Of Contents

    Contents Caution Features Controls, Indicators and Connections Menu Organization & Adjustment Menu Contents Other Functions DVI ANALOG/ DVI DIGITAL / HDMI Support Resolution Product Specifications Optional Accessories...

  • Page 3: Caution

    Caution ◦ Power Requirements ◦ In case the product needs service, consult an authorized TVLogic Reseller. - AC 100 ~ 240V Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean ◦...

  • Page 4: Features

    - This product can be remote controlled simply with a cable connection without any additional peripheral equipment attached to the unit. RS422/UMD feature support ◦ - This product supports protocols provided by TVLogic or a TSL protocol. RS232 support ◦ - Supports firmware updates & color-calibration through serial communication.
  • Page 5 - Press the button briefly to activate the main menu. - Used to control the monitor with protocol provided by TVLogic or to support TSL protocol. - Press the button for a long time to activate the Input Select menu. Use the Up and Down menu to change the Input Select menu.

  • Page 6: Menu Organization & Adjustment

    - Ethernet and USB port for easy firmware updates. 1) Menu Organization ~ AC IN ◦ Below is the organization of the product’s menu. - 100 ~ 240V AC 50/60Hz SDI A LVM-420A 1080/60i <Video input> PAGE I >> PAGE II Video input connection method. BRIGHT CONTRAST...

  • Page 7: Menu Contents

    - Only available in COMPOSITE 1/2/3 and S-VIDEO modes containing a NTSC signal. Below is the description for each function of the PICTURE menu. ◦ VGA H POSITION SDI A LVM-420A 1080/60i - Controls horizontal position of DVI analog image between MIN (-15) and MAX (15). PAGE I >> PAGE II BRIGHT...
  • Page 8 A 444 12BIT_YCbCr, A 444 12BIT_RGB, A 422 12BIT_YCbCr, B 444 10/12BIT_YCbCr, B 444 10/12BIT_ Below is the description for each function of the VIDEO menu. RGB, B 422 12BIT_YCbCr, B 422 10BIT_YCbCr, 60P). - Automatically detects when Payload signal appears in normal mode. SDI A LVM-420A 1080/60i DITHERING OUTPUT MODE SELECT ◦...
  • Page 9 - The value is selectable between MIN (-100) and MAX (+100). Below is the description for each function of the COLOR menu. - Adjusts red color of dark section. - Only available in CUSTOM 1/2/3 mode. SDI A LVM-420A 1080/60i COLOR TEMP 6500K BIAS GREEN ◦...
  • Page 10 - CC 1 ~ CC 4 supported. Below is the description for each function of the DISPLAY menu. ◦ 708 SERVICE SELECT SDI A LVM-420A 1080/60i - Controls Closed Caption 708 service. PAGE I >> PAGE II - SERVICE 1 ~ SERVICE 6 supported.
  • Page 11 The pin positions are as follows : ◦ [5] GPI REMOTE (RJ-45) Below is the description for each function of the GPI menu. 1: Pin1 SDI A LVM-420A 1080/60i SDI A LVM-420A 1080/60i 2: Pin2 PAGE I >> PAGE II PAGE II >>...
  • Page 12 Menu Contents Menu Contents MONITOR ID TALLY1 COLOR ~ TALLY4 COLOR ◦ ◦ - Sets the ID of each monitor for the TV Logic control protocol or DYNAMIC UMD using RS-422/485 - This item sets the color of each TALLY1, TALLY2, TALLY3 and TALLY4 . communication.
  • Page 13 Menu Contents Menu Contents * Tally Type – Default <Dynamic UMD Protocol (TSL V3.1)> - S-8C(Single 8 Character) & S-16C(Single 16 Character) * Transmission (18 Byte) (PC or Device -> Monitor) HEADER CONTROL BYTE DISPLAY DATA Bit 1 Bit 1 Operation (1 BYTE) (1 BYTE)
  • Page 14 Menu Contents Menu Contents * D-UMD TALLY TPYE – USER COLOR UMD BG. TRANS ◦ - Color selections between TALLY1 ~ TALLY4. - This function sets the transparency of the UMD character’s background box. - Available modes are SCALE DOWN, OPAQUE, 50%, 90% and 100%. - SCALE DOWN function reduces images and places on UMD not to overlap with UMD and images.
  • Page 15 - With FIT MARKER “ON”, the safety area is displayed relative to the marker in use. With FIT MARKER Below is the description for each function of the MARKER menu. “OFF”, the safety area is displayed relative to the incoming source. - FIT MARKER ON/OFF displays as shown below. SDI A LVM-420A 1080/60i SDI A LVM-420A 1080/60i PAGE I >>...
  • Page 16 - Available values are between 0 ~ 30. The higher the number the brighter the waveform will be. Below is the description for each function of the WAVEFORM menu. ◦ WAVEFORM TRANS SDI A LVM-420A 1080/60i SDI A LVM-420A 1080/60i - Controls the transparency level of the WAVEFORM/VECTOR.
  • Page 17 - Selected values in Y MAX, Y MIN, C MAX, C MIN are indicated in WAVEFORM/VECTOR or Y/Cb/Cr. - If Y PICTURE BLINK or C PICTURE BLINK is enabled, the section of image that exceeds the selected SDI A LVM-420A 1080/60i values of Y MAX, Y MIN, C MAX and C MIN blinks.
  • Page 18 * 16 CH(HOR.) : Displays 8 channel on top left and 8 channels on top right of the screen horizontally. * 16 CH(HOR.) : Displays 8 channel on center left and 8 channels on center right of the screen SDI A LVM-420A 1080/60i SDI A...

  • Page 19: Other Functions

    Menu Contents Other Functions OSD POSITION ◦ [1] INPUT SIGNAL - Controls the OSD position. - Available positions are Center, Top-Left(L-T), Bottom-Left(L-B), Top-Right(T-R) and Bottom-Right(R-B). ◦ This product is capable of processing all input signals usable. TheInput settings are as follows: ◦...
  • Page 20 Other Functions Other Functions [2] SCAN BUTTON This product supports various scan modes. ◦ Press [DISPLAY] - [SCAN] menu on the monitor OSD to activate different scan modes. ◦ <MID CENTER> <MID LEFT> <TOP LEFT> 1. Press [SCAN] button continuously to activate various scan modes: OVER SCAN ->...
  • Page 21 Other Functions DVI ANALOG / DVI DIGITAL / HDMI Support Resolution [3] ASPECT BUTTON DVI ANALOG/DVI DIGITAL/HDMI SUPPORT RESOLUTION 1. Four different aspect modes are available. DVI-ANALOG mode support resolution: ◦ When input signal is SDI -A/B, Composite 1/2/3 and Input Signal Format is SD : Resolution Frequency 1) 4:3 mode : Cuts left and right of the original image to fit to 4:3 aspect ratio.

  • Page 22: Product Specifications

    Product Specifications Product Specifications LVM-420A LVM-460A Size 42” Size 46” Resolution 1366 X 768 (16:9) Resolution 1920 x 1080 (16:9) Pixel Pitch 0.4845(H) x 0.4845(W) mm Pixel Pitch 0.53025(H) x 0.53025(W) mm Color Depth 1.06B(R/G/B 10bit, Dither) Color Depth 1.06B(R/G/B 10bit, Dither)

  • Page 23: Optional Accessories

    Optional Accessories Product Specifications LVM-550A Size 54.6” Resolution 1366 X 768 (16:9) Pixel Pitch 0.4845(H) x 0.4845(W) mm Color Depth 1.06B(R/G/B 10bit, Dither) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 450 cd/ m (Center) Contrast Ratio 4000 : 1...
  • Page 24 Memo...
  • Page 25 FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.tv 12F, ACE HIGH-END 8, 84 Gasan digital 1-ro, Geumcheon-gu, Seoul, 153-802, KOREA 부사장 TEL : +82-70-8668-6611, FAX : 82-2-6123-3201, E-mail : sales@ t vlogic.co.kr 조 성 일 153-802 서울특별시 금천구 가산동 345-4 에이스하이엔드 8차 12층...
