Chapter 1 BDCOM S2510-C Introduction

The section describes the characteristics and parameters of BDCOM S2510-C and
gives an overview of BDCOM S2510-C.

1.1 Appearance Description for Standard Configuration

The built-in ports of BDCOM S2510-C are: 8 gigabit TX ports, 2 GSFP and 1 CLI
port. See table 1-1.
Port
1000M TX port
GSFP interface
CLI port
Besides, BDCOM S2510-C switch has one grounding column and one power input at
its back.
Figure 1- 1 Front template of the BDCOM S2510-C switch
Table 1- 2 Parts at the front template of the BDCOM S2510-C switch
No. Abbrev.
1 Reset
PWR
2
SYS
3 1-8
Table 1- 1 Attributes of the built-in port
RJ45 interface, with LINK/ACT/Speed indicator
GSFP interface, with LINK/ACT indicator
A rate of 9600bps, RJ45 interface
Name
Reset
Power indicator
System indicator
Link/Act indicator on
each port
BDCOM S2510-C Hardware Installation Manual
Attribute
Description
Keep the device powered on, press the
button "Reset" for 6s, and the system will
return to the default setting.
If the switch is powered on, the indicator
is on.
&
If the switch is started, the system
indicator flickers.
Always on in orange: 10/100M
