Configure the Polycom DMA System Server(s)

Polycom, Inc.
Connect the GB 1 Ethernet port of each server to the enterprise
a
network to be used for management (or combined) traffic.
This is the eth0 network interface, which must be used for this
purpose.
For a split network configuration, connect the GB 3 Ethernet port of
b
each server to the network to be used for signaling traffic.
This is the eth2 network interface, which must be used for this
purpose.
For a two-node system, connect one of the provided crossover cables
c
between the GB 2 ports of the two servers.
This is the eth1 network interface, which must be used for this
purpose.
Don't turn on the server(s) at this time.
Remove the bezel(s) from the server(s).
9
You configure the Polycom DMA system server(s) using the Polycom DMA
USB Configuration Utility on the USB memory stick.
To configure the system server(s) without using the USB memory stick, see
"Alternate Procedure: Configure the Polycom DMA System Server(s) Without Using
the USB Stick" on page 11.
To configure the Polycom DMA system server(s)
Connect the USB memory stick containing the Polycom DMA USB
1
Configuration Utility to a Windows PC.
When prompted, elect to run the Configuration Utility.
2
If autorun doesn't work or is turned off, navigate to the USB memory stick using My
Computer, Windows Explorer, or another file manager. Then start the Configuration
Utility by double-clicking dma7000-usb-gui.exe.
In the DMA USB Configuration Utility window, click Configure the
3
System Parameters.
® ™
Polycom DMA System Server Setup
