AUMA SQ 05.2 Operation Instructions Manual

Control unit - electromechanical with actuator controls
Hide thumbs Also See for SQ 05.2:
Table of Contents

Advertisement

Quick Links

Part-turn actuators
SQ 05.2
SQ 14.2
SQR 05.2
SQR 14.2
Control unit - electromechanical
with actuator controls
AC 01.2 Intrusive
Control
Parallel
Profibus DP
Profinet
Modbus RTU
Modbus TCP/IP
EtherNet/IP
Foundation Fieldbus
HART
Operation instructions
Assembly and commissioning

Advertisement

Table of Contents
loading

Related Manuals for AUMA SQ 05.2

Summary of Contents for AUMA SQ 05.2

  • Page 1 Part-turn actuators SQ 05.2 SQ 14.2 SQR 05.2 SQR 14.2 Control unit - electromechanical with actuator controls AC 01.2 Intrusive Control Parallel Profibus DP Profinet Modbus RTU Modbus TCP/IP EtherNet/IP Foundation Fieldbus HART Operation instructions Assembly and commissioning...

  • Page 2: Table Of Contents

    This document contains information for assembly, commissioning and maintenance staff. Reference documents: Manual (Operation and setting) of actuator controls AC 01.2 Profinet Manual (Fieldbus device integration) of actuator controls AC 01.2 Profinet Reference documents are available on the Internet at: http://www.auma.com. Table of contents Page Safety instructions.........................
  • Page 3 Indications during commissioning 8.2. Indications in the display 8.2.1. Feedback signals from actuator and valve 8.2.2. Status indications according to AUMA classification 8.2.3. Status indications according to NAMUR recommendation 8.3. Indication lights of local controls 8.4. Mechanical position indication via indicator mark Signals (output signals)......................
  • Page 4 Disposal and recycling Technical data......................... 14.1. Technical data Part-turn actuator 14.2. Technical data Actuator controls 14.3. Tightening torques for screws Spare parts..........................15.1. Part-turn actuators SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 15.2. Stellantriebs-Steuerung AC 01.2 mit Elektroanschluss SF Index............................

  • Page 5: Safety Instructions

    Any device modification requires prior written consent of the manufacturer. 1.2. Range of application AUMA part-turn actuators SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 are designed for the operation of industrial valves, e.g. butterfly valves and ball valves.

  • Page 6: Warnings And Notes

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Safety instructions AC 01.2 Intrusive Profinet Buried service Continuous underwater use (observe enclosure protection) Potentially explosive areas Radiation exposed areas in nuclear power plants No liability can be assumed for inappropriate or unintended use.

  • Page 7: Short Description

    App and software Using the AUMA CDT software for Windows-based computers (notebooks or tablets) and the AUMA Assistant App, actuator data can be uploaded and read, settings can be modified and stored. The connection between computer and AUMA actuator is established wireless via Bluetooth interface. With the AUMA Cloud, we provide an interactive platform to collect and assess e.g.
  • Page 8 The AUMA Cloud is the driving element of the digital AUMA world, acting as interactive platform for efficient maintenance of AUMA actuators at moderate cost. The AUMA Cloud collects all device data of all actuators within one site and provides a clear overview at a glance. Detailed analysis provides valuable information on potential maintenance requirements.

  • Page 9: Name Plate

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Name plate Name plate Each device component (actuator, actuator controls, motor) is equipped with a name plate. Figure 4: Arrangement of name plates Actuator name plate...
  • Page 10 Figure 6: Name plate for actuator controls (example) Type designation Order number Serial number Actuator terminal plan Actuator controls terminal plan Mains voltage AUMA power class for switchgear Permissible ambient temperature Enclosure protection [10] Control [11] Data Matrix code Motor name plate Figure 7: Motor name plate (example) (= manufacturer logo);...
  • Page 11 The rated power (nominal power) of the actuator motor is indicated in kW on the motor name plate. For the assignment of the AUMA power classes to the nominal power of the motor types, refer to the separate electrical data sheets.
  • Page 12 SQR 14.2 Control unit - electromechanical Name plate AC 01.2 Intrusive Profinet When registered as authorised user, you may use our AUMA Assistant App to scan Data Matrix code the Data Matrix code and directly access the order-related product documents without having to enter order number or serial number.

  • Page 13: Transport And Storage

    Perform lift trial at low height to eliminate any potential danger e.g. by tilting. Figure 9: Example: Lifting the actuator Weights Table 5: Weight for AC 01.2 actuator controls with electrical connection type: Weight approx. [kg] AUMA plug/socket connector with screw-type connection...

  • Page 14: Storage

    SQR 12.2 SQ 14.2/ SQR 14.2 Indicated weight includes AUMA NORM part-turn actuator with 3-phase AC motor, electrical con- nection in standard version, unbored coupling and handwheel. For other output drive types, consider additional weights. lndicated weight includes AUMA NORM part-turn actuator with 3-phase AC motor, electrical connec- tion in standard version, and handwheel, including base and lever.
  • Page 15 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Transport and storage Risk of damage due to excessively low temperatures! Actuator controls may only be stored permanently down to 30 °C. On request, actuators controls may be transported in specific cases and for short duration at temperatures down to 60 °C.

  • Page 16: Assembly

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Assembly AC 01.2 Intrusive Profinet Assembly 5.1. Mounting position When using grease as lubricant, the product described herein can be operated in any mounting position. When using oil instead of grease within the actuator gear housing, perpendicular mounting position is specified whereby the flange is pointing downward.

  • Page 17: Overview On Coupling Variants

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Assembly 5.3.1. Overview on coupling variants Design Figure 11: Valve attachment via coupling Bore with keyway Square bore Bore with two-flats For valve attachments according to EN ISO 5211...
  • Page 18 Valve shaft Grub screw Clamping washer and screw with curved spring lock washer Figure 13: Mounting positions for coupling Table 8: Mounting position of the coupling within fitting dimensions according to AUMA definition Dimensions [mm] SQ 05.2 SQ 07.2 SQ 10.2 SQ 12.2...
  • Page 19 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Assembly Fit actuator. If required, slightly turn actuator until splines of coupling engage. Figure 14: Ensure that the spigot (if provided) fits uniformly in the recess and that the flanges Information are in complete contact.

  • Page 20: Mounting Positions Of Local Controls

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Assembly AC 01.2 Intrusive Profinet 5.4. Mounting positions of local controls Figure 15: Mounting positions The mounting position of the local controls is implemented according to the order. If, after mounting the actuator to the valve or the gearbox on site, the local controls are in an unfavourable position, the mounting position can be changed at a later date.

  • Page 21: Electrical Connection

    It can plan also be requested from AUMA (state order number, refer to name plate) or downloaded directly from the Internet (http://www.auma.com). The actuators are suitable for use in TN and TT networks with directly grounded star Permissible networks point for nominal voltages up to maximum 690 V AC.
  • Page 22 1.5 kW 16 A (g/R) I²t<1,500A²s The AUMA power class (A1, B1, ...) is indicated on the actuator controls name plate Consider the motor starting current (IA) (refer to electrical data sheet) when selecting the circuit breaker. We recommend tripping characteristics D or K for circuit breakers in accordance with IEC 60947-2.
  • Page 23 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection The following minimum requirements with regard to LAN cables apply for Profinet Profinet cables networks: Category 5 according to ISO/IEC 11801 Edition 2.0 Class D.

  • Page 24: Sf Electrical Connection (Auma Plug/Socket Connector)

    Short description Control contacts also available as crimp-type connection as an option. SF version. For power and control cable connection, remove the AUMA plug/socket connector and the socket carrier from terminal compartment. Removing the cover is sufficient for connecting the fieldbus cables.

  • Page 25: Terminal Compartment (For Mains Connection): Open

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection 6.2.1. Terminal compartment (for mains connection): open Figure 18: Open mains terminal compartment Connection housing Screws for frame O-ring Screws for socket carrier...

  • Page 26: Cable Connection

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Electrical connection AC 01.2 Intrusive Profinet 6.2.2. Cable connection Table 16: Terminal cross sections and terminal tightening torques Designation Terminal cross sections Tightening torques Power contacts 6 mm (flexible) 1.5 Nm...

  • Page 27: Terminal Compartment (For Mains Connection): Close

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection 6.2.3. Terminal compartment (for mains connection): close Figure 21: Close mains terminal compartment Connection housing Screws for connection housing O-ring Screws for socket carrier...

  • Page 28: Fieldbus Terminal Compartment: Open

    O-ring Cable entries for fieldbus cables Blanking plug The AUMA plug/socket connector is equipped with a connection board for connecting the fieldbus cables. When removing the cover [1], the connection board is easily accessible. Electric shock due to presence of hazardous voltage! Death or serious injury.

  • Page 29: Profinet Cables: Connect

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection 6.2.5. Profinet cables: connect Figure 24: Profinet connection board with connection terminals Profinet cable from previous device Profinet cable to next device (For line topology or redundant ring/MRP - Media Redundancy Protocol) Profinet connection is made individually by means of a safe Ethernet-capable insulation displacement connection.
  • Page 30 (supplied within electrical connector). Further connectors are available with AUMA (e.g. for line topology or redundant ring) on request. Order designations: RJ-45 Profinet connector for Cat.5 (as included in scope of delivery): AUMA article number K009.706 Option: RJ-45 Profinet connector for Cat.6 cables: AUMA article number K009.705...
  • Page 31 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection Table 21: NETS (Network Status) Status Explanation Red LED: off + Offline Absence of power supply or no connection to IO controller Green LED: off...

  • Page 32: Fieldbus Terminal Compartment: Close

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Electrical connection AC 01.2 Intrusive Profinet 6.2.6. Fieldbus terminal compartment: close Figure 26: Close fieldbus terminal compartment Cover (fieldbus terminal compartment) Screws for cover O-ring Cable glands for fieldbus cables Blanking plug Clean sealing faces of cover [1] and housing.

  • Page 33: Accessories For Electrical Connection

    Versions with potentiometer in the actuator are not suitable. We recommend using an AUMA “LSW” cable set . If the AUMA cable set is not used: Use suitable flexible and screened connecting cables. When using connecting cables, e.g. of the heater or switch, requiring direct...

  • Page 34: Parking Frame

    AC 01.2 Intrusive Profinet 6.3.2. Parking frame Figure 28: Parking frame, example with AUMA plug/socket connector and cover Parking frame for safe storage of a disconnected plug or cover. Application For protection against touching the bare contacts and against environmental influences.

  • Page 35: External Earth Connection

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Electrical connection 6.3.4. External earth connection Figure 30: Earth connection for part-turn actuator External earth connection (U-bracket) for connection to equipotential compensation. Application Table 24:...

  • Page 36: Operation

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Operation AC 01.2 Intrusive Profinet Operation 7.1. Manual operation For purposes of setting and commissioning, in case of motor or power failure, the actuator may be operated manually. Manual operation is engaged by an internal change-over mechanism.

  • Page 37: Actuator Operation From Remote

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Operation Figure 31: Local controls Push button for operation command in direction OPEN Push button STOP Push button for operation command in direction CLOSE Push button RESET Selector switch Hot surfaces, e.g.

  • Page 38: Menu Navigation Via Push Buttons (For Settings And Indications)

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Operation AC 01.2 Intrusive Profinet For actuators equipped with a positioner, it is possible to change over between OPEN Information - CLOSE control (Remote OPEN-CLOSE) and setpoint control (Remote SET- POINT).

  • Page 39: Menu Layout And Navigation

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Operation 7.3.1. Menu layout and navigation Groups The indications on the display are divided into 3 groups: Figure 33: Groups Start menu Status menu Main menu Status menu and main menu are marked with an ID.

  • Page 40: User Level, Password

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Operation AC 01.2 Intrusive Profinet 7.4. User level, password The user level defines which menu items or parameters can be displayed or modified User level by the active user.

  • Page 41: Timeout For Incorrect Password Entry

    A timeout for incorrect password entry is provided with actuator controls.This prevents unauthorised access by systematic trials. The timeout is active for incorrect entries via the local controls as well as incorrect entries via our software tools (AUMA CDT, AUMA Assistant App). After five subsequent incorrect trials, further entry is inhibited for one minute.
  • Page 42 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Operation AC 01.2 Intrusive Profinet Set selector switch to position 0 (OFF). Select main menu Press push button C Setup and hold it down for approx. 3 seconds. Display goes to main menu and indicates: ▶ Display...

  • Page 43: Indications

    If no entry is made over a longer period of time (approx. 1 minute), the display automatically returns to the first status indication. 8.2. Indications in the display Menus and functions depend on the actuator controls firmware version! Should menus or functions be unavailable, please contact the AUMA Service.

  • Page 44: Feedback Signals From Actuator And Valve

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Indications AC 01.2 Intrusive Profinet The status bar (first row in the display) indicates the operation mode [1], the presence Status bar of an error [2] and the ID number [3] of the current display indication.
  • Page 45 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Indications Operation commands (S0003) The display S0003 indicates: active operation commands, like e.g.: Operation in direction CLOSE or in direc- tion OPEN the actual value E2 as bar graph indication and as value between 0 and 100...

  • Page 46: Status Indications According To Auma Classification

    Pause for operation in direction OPEN Pause for operation in directions OPEN and CLOSE 8.2.2. Status indications according to AUMA classification These indications are available if the parameter Diagnostic classific. M0539 is set to AUMA. Warnings (S0005) If a warning has occurred, the display shows S0005: the number of warnings occurred a blinking question mark after approx.

  • Page 47: Status Indications According To Namur Recommendation

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Indications Figure 51: Fault For further information, please also refer to <Corrective action>. 8.2.3. Status indications according to NAMUR recommendation These indications are available, if the parameter Diagnostic classific. M0539 is set to NAMUR.

  • Page 48: Indication Lights Of Local Controls

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Indications AC 01.2 Intrusive Profinet Figure 54: Maintenance required For further information, please also refer to <Corrective action>. Failure (S0011) The S0011 indication shows the causes of the failure indication according to NAMUR recommendation NE 107.

  • Page 49: Mechanical Position Indication Via Indicator Mark

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Indications Indication light 2 = Torque fault CLOSE Indication light 3 = Thermal fault Indication light 4 = Torque fault OPEN Indicat. light 5 (right) = End p. OPEN, blink Signal interm.

  • Page 50: Signals (Output Signals)

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Signals (output signals) AC 01.2 Intrusive Profinet Signals (output signals) 9.1. Signals via Profinet Feedback signals via Profinet can be configured using the engineering tool of the DCS/PLC and the GSD file of actuator controls with Profinet (available for download at www.auma.com).
  • Page 51 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Signals (output signals) Signal: E2 = 0/4 20 mA (galvanically isolated) Valve position Designation in the wiring diagram: AOUT1 (position) For further information on this topic, please refer to Manual (Operation and setting).

  • Page 52: Commissioning (Basic Settings)

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (basic settings) AC 01.2 Intrusive Profinet Commissioning (basic settings) Set selector switch to position 0 (OFF). Information: The selector switch is not a mains switch. When positioned to 0 (OFF), the actuator cannot be operated.

  • Page 53: Set End Stop Closed

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (basic settings) Figure 59: End stop Screw plug for end stop OPEN Setting screw for end stop OPEN Screw plug for end stop CLOSED...

  • Page 54: Type Of Seating: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (basic settings) AC 01.2 Intrusive Profinet If the valve end position is not reached: Slightly turn setting screw [2] counterclockwise until valve end position OPEN can be safely set.

  • Page 55: Open Switch Compartment

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (basic settings) Press Display indicates the current setting: Limit or Torque The bottom row of the display indicates either: Edit → continue with step 6 Save →...

  • Page 56: Torque Switching: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (basic settings) AC 01.2 Intrusive Profinet If indicator disc [3] is available: Remove indicator disc [3] using a spanner (as lever). Information: To avoid damage to paint finish, use spanner in combination with soft object, e.g.

  • Page 57: End Position Closed (Black Section): Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (basic settings) Figure 61: Setting elements for limit switching Black section: Setting spindle: End position CLOSED Pointer: End position CLOSED Mark: End position CLOSED is set...

  • Page 58: Intermediate Positions: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (basic settings) AC 01.2 Intrusive Profinet 10.6. Intermediate positions: set Actuators equipped with DUO limit switching contain two intermediate position switches. One intermediate position may be set for each running direction.

  • Page 59: Test Run

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (basic settings) As soon as the pointer [5] moves to mark [6]: Stop turning and release setting spindle. The intermediate position setting in running direction OPEN is complete.

  • Page 60: Reference Operation Position Feedback: Perform

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (basic settings) AC 01.2 Intrusive Profinet Operate actuator using push buttons OPEN, STOP, CLOSE. The limit switching is set correctly if (default indication): the yellow indication light/LED1 is illuminated in end position CLOSED the green indication light/LED5 is illuminated in end position OPEN the indication lights go out after travelling into opposite direction.

  • Page 61: Close Switch Compartment

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (basic settings) 10.9. Close switch compartment If options (e.g. potentiometer, position transmitter) are available: Only close switch compartment once all optional equipment has been successfully set.

  • Page 62: Commissioning (Optional Equipment Settings)

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (optional equipment settings) AC 01.2 Intrusive Profinet Commissioning (optional equipment settings) 11.1. EWG 01.1 electronic position transmitter EWG 01.1 electronic position transmitter signals the remote position or the valve position.

  • Page 63: Measuring Range: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (optional equipment settings) Table 30: Short overview on push button functions Push but- Function tons [S1] + [S2] → press simultaneously for 5 s: Activate setting mode [S1] →...

  • Page 64: Current Values : Adjust

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (optional equipment settings) AC 01.2 Intrusive Profinet Perform setting in the second end position following the same steps. Approach both end positions again to check the setting. If the measuring range cannot be set: Refer to <Faults during commissioning>.

  • Page 65: Potentiometer: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Commissioning (optional equipment settings) Figure 66: View on control unit Potentiometer 11.2.1. Potentiometer: set Information Due to the ratio of the reduction gearing, the complete resistance range/stroke is not always covered.

  • Page 66: Measuring Range: Set

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Commissioning (optional equipment settings) AC 01.2 Intrusive Profinet Figure 67: View on control unit when switch compartment is open Potentiometer (travel sensor) Potentiometer min. (0/4 mA) Potentiometer max. (20 mA)

  • Page 67: Corrective Action

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Corrective action Corrective action 12.1. Faults during commissioning Table 33: Faults during operation/commissioning Fault Description/cause Remedy Mechanical position indicator cannot Reduction gearing is not suitable for actuator swing Set gear stage of the reduction gearing.
  • Page 68 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Corrective action AC 01.2 Intrusive Profinet Table 34: Faults and warnings via status indications in the display Indication on display Description/cause Remedy S0001 Instead of the valve position, a status text is dis- For a description of the status texts, refer to Manual played.
  • Page 69 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Corrective action Warnings and Out of specification Indication on display Description/cause Remedy Wrn input AIN 1 Warning: Loss of signal analogue input 1 Check wiring.
  • Page 70 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Corrective action AC 01.2 Intrusive Profinet Faults and Failure Indication on display Description/cause Remedy Torque fault OPEN Torque fault in direction OPEN Perform one of the following measures: Issue operation command in direction CLOSE.

  • Page 71: Fuses

    Selector switch is not in position REMOTE. Set selector switch to position REMOTE. Service active Operation via service interface (Bluetooth) and Exit service software. AUMA CDT service software. Disabled Actuator is in operation mode Disabled. Check setting and status of function <Local controls enable>.

  • Page 72: Fuse Replacement

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Corrective action AC 01.2 Intrusive Profinet Table 39: Secondary fuses F3 (internal 24 V DC supply) G fuse according to IEC 60127-2/III AUMA art. no. Size 5 x 20 mm Voltage output (power supply unit) = 24 V 2.0 A T;...

  • Page 73: Test/Replace Fuses

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Corrective action 12.3.2.2. Test/replace fuses F3/F4 Loosen screws [1] and remove cover [2] on the rear of the actuator controls. Figure 69: Check fuses. The power supply unit has measuring points (solder pins) allowing to perform...
  • Page 74 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Corrective action AC 01.2 Intrusive Profinet The test is performed by simulating the motor protection signal via actuator controls local controls: Required user level: Specialist (4) or higher. Diagnostics M0022 TMS proof test M1950 Set selector switch to position 0 (OFF).

  • Page 75: Servicing And Maintenance

    Therefore, we recommend contacting our service. Only perform servicing and maintenance tasks when the device is switched off. AUMA AUMA offers extensive service such as servicing and maintenance as well as Service & Support customer product training. For the contact addresses, refer to our website (www.auma.com).
  • Page 76 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Servicing and maintenance AC 01.2 Intrusive Profinet Plastic materials Greases and oils The following generally applies: Greases and oils are hazardous to water and must not be released into the environment.

  • Page 77: Technical Data

    Information on the customer-specific version, refer to the order-related data sheet. The technical data sheet can be downloaded from the Internet in both German and English at ht- tp://www.auma.com (please state the order number). 14.1. Technical data Part-turn actuator Features and functions...
  • Page 78 60664-1 Vibration resistance according to 2 g, 10 to 200 Hz (AUMA NORM), 1 g, 10 to 200 Hz (for actuators with AM or AC integral controls) IEC 60068-2-6 Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be derived from this.
  • Page 79 AUMA silver-grey (similar to RAL 7037) Option: Available colours on request Lifetime AUMA part-turn actuators meet or even exceed the lifetime requirements of EN 15714-2. Detailed in- formation can be provided on request. Further information EU Directives Machinery Directive 2006/42/EC...

  • Page 80: Technical Data Actuator Controls

    Bluetooth Class II Chip, Version 2.1: With a range up to 10 m in industrial environments supports the SSP Bluetooth profile (Serial Port Profile). Communication interface Required accessories: AUMA CDT (Commissioning and Diagnostic Tool for Windows-based PC) AUMA Assistant App (Commissioning and Diagnostic Tool)
  • Page 81 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Technical data Features and functions Profinet acyclic services (option) Access to parameters, the electronic name plate and the operating and diagnostic data with acyclic write/read services Integration in configuration tools and asset management systems via FDI package.
  • Page 82 Monitoring the motor temperature in combination with thermoswitches within actuator motor Option: PTC tripping device in combination with PTC thermistors within actuator motor Electrical connection Standard: AUMA plug/socket connector with screw-type connection Option: Gold-plated control plug (sockets and plugs) Threads for cable entries Standard: Metric threads...
  • Page 83 Option: Terminal compartment additionally sealed against interior of actuator controls (double sealed) According to AUMA definition, enclosure protection IP68 meets the following requirements: Depth of water: Maximum 8 m head of water Continuous immersion in water: maximal 96 hours Up to 10 operations during immersion Modulating duty is not possible during immersion.

  • Page 84: Tightening Torques For Screws

    Cable length between actuator and actuator controls is max. 100 m. An MWG is required for position feedback. Programming software AUMA CDT (Commissioning and Diagnostic Tool for Windows-based PC) AUMA Assistant App (Commissioning and Diagnostic Tool) Torque measurement flange DMF Accessory for torque measurement for SA/SAR 07.2...

  • Page 85: Spare Parts

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Spare parts Spare parts 15.1. Part-turn actuators SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2...
  • Page 86 AC 01.2 Intrusive Profinet Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary from actual delivery.

  • Page 87: Stellantriebs-Steuerung Ac 01.2 Mit Elektroanschluss Sf

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Spare parts 15.2. Stellantriebs-Steuerung AC 01.2 mit Elektroanschluss SF...
  • Page 88 AC 01.2 Intrusive Profinet Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary from actual delivery.

  • Page 89: Index

    SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Index Index Earth connection Electrical connection Electronic position transmitter 62, 65 Accessories (electrical con- nection) Enclosure protection 9, 10, 10, 78, 83 Actual value - indication on...
  • Page 90 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical Index AC 01.2 Intrusive Profinet Main menu Range of application Mains frequency 10, 10 Rated current Mains voltage 10, 10, 21 Rated power Maintenance 5, 75, 75 Recycling Maintenance required - indic-...
  • Page 91 SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit - electromechanical AC 01.2 Intrusive Profinet Index Valve position - indication on display Vibration resistance Voltage range Wall bracket Warnings - indication on dis- play Wiring diagram 11, 21 Year of manufacture...
