1 Safety Instructions
Basic Information on Safety
Range of Application
Applications in Ex Zone 22 (Option)
Warnings and Notes
References and Symbols
2 Identification
Name Plate
Short Description
3 Transport, Storage and Packaging
Transport
Storage
Packaging
4 Assembly
Mounting Position
Handwheel Fitting
Part-Turn Actuator to Valve: Mount
Output Drive for Coupling
4.3.1.1. Part-Turn Actuator (with Coupling): Mount to Valve
Mounting Positions of Local Controls
Mounting Positions: Modify
5 Electrical Connection
Basic Information
SF Electrical Connection (AUMA Plug/Socket Connector)
Terminal Compartment (for Mains Connection): Open
Cable Connection
Terminal Compartment (for Mains Connection): Close
Fieldbus Terminal Compartment: Open
Profinet Cables: Connect
Fieldbus Terminal Compartment: Close
Accessories for Electrical Connection
Actuator Controls on Wall Bracket
Parking Frame
DS Intermediate Frame for Double Sealing
External Earth Connection
Operation
Manual Operation
Manual Operation: Engage
Manual Operation: Disengage
Motor Operation
Local Actuator Operation
Actuator Operation from Remote
Menu Navigation Via Push Buttons (for Settings and Indications)
Menu Layout and Navigation
User Level, Password
Password Entry
Password Change
Language in the Display
Language Change
Indications
Indications During Commissioning
Indications in the Display
Feedback Indications from Actuator and Valve
Status Indications According to AUMA Classification
Status Indications According to NAMUR Recommendation
Indication Lights of Local Controls
Mechanical Position Indication (Self-Adjusting)
Mechanical Position Indication Via Indicator Mark
Signals (Output Signals)
Signals Via Profinet
Status Signals Via Output Contacts (Digital Outputs)
Assignment of Outputs
Coding the Outputs
Analogue Signals (Analogue Outputs)
Commissioning (Basic Settings)
End Stops in Part-Turn Actuator
End Stop CLOSED: Set
End Stop OPEN: Set
Type of Seating: Set
Torque Switching: Set
Limit Switching: Set
Test Run
Direction of Rotation at Mechanical Position Indicator: Check
Limit Switching: Check
Commissioning (Settings in the Actuator)
Switch Compartment: Open/Close
Mechanical Position Indicator (Self-Adjusting)
Mechanical Position Indicator: Set
Gear Stage of the Reduction Gearing: Test/Set
Mechanical Position Indication Via Indicator Mark (Not Self-Adjusting)
Mechanical Position Indicator: Set
Gear Stage of the Reduction Gearing: Test/Set
Corrective Action
Faults During Commissioning
Fault Indications and Warning Indications
Fuses
Fuses Within the Actuator Controls
Fuse Replacement
Replace Fuses F1/F2
Test/Replace Fuses
Motor Protection (Thermal Monitoring)
Servicing and Maintenance
Preventive Measures for Servicing and Safe Operation
Maintenance
Disposal and Recycling
Technical Data
Technical Data Part-Turn Actuator
Technical Data Actuator Controls
Spare Parts
Part-Turn Actuators SQ
Sq 14.2/Sqr 05.2
AUMATIC AC 01.2 Actuator Controls with SF Electrical Connection
Certificates
Declaration of Incorporation and EU Declaration of Conformity
Index
Addresses
Advertisement
Quick Links
1
Electrical Connection
2
Basic Information
3
Sf Electrical Connection (Auma Plug/Socket Connector)
Download this manual
Part-turn actuators
SQ 05.2
SQ 14.2
SQR 05.2
SQR 14.2
Control unit: electronic (MWG)
with actuator controls
AC 01.2 Non-Intrusive
Control
Parallel
Profibus DP
Profinet
Modbus RTU
Modbus TCP/IP
Foundation Fieldbus
HART
Operation instructions
Assembly, operation, commissioning
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
