Installation
3.4
RS-232 Connection R2 Port (only available on FS-QS-122X Models)
TX
RX
SG
Figure 14: RS-232 R2 Connection Port
Refer to Section
8
for further hardware connection options.
The following Baud Rates are supported on the R2 Port:
4800, 9600, 19200, 38400, 57600, 115200
QuickServer Start-up Guide
20
