Equipment Setup
Termination Resistor
Termination Resistor
Jumper
Figure 6: Termination Resistor Jumper
Termination resistors are also used to reduce noise. These pull the two lines of an idle bus together.
However, they would override the effect of any bias resistors, if connected.
QuickServer Start-up Guide
14
