Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM, SMPTE 292M
Input level ..................................... 0.0 V to 5.0 Vp-p
Output level ................................... 0.6 Vp-p for component video (tri-level sync)
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Polarity............................................ Positive or negative (selectable)
Control/remote — processor/decoder/scaler
Serial control port ......................... (1) RS-232 or RS-422, 9-pin female D connector
Baud rate and protocol ................. 300 to 115200 baud (default: 9600), 8 data bits, 1 stop bit, no parity
Serial control pin configurations
9-pin D connector .............. RS-232: 2 = TX, 3 = RX, 5 = GND
2.5 mm mini stereo jack .... Tip = TX, ring = RX, sleeve = GND
Ethernet control port..................... 1 RJ-45 female connector
Ethernet data rate .......................... 10/100Base-T, half/full duplex with autodetect
Ethernet protocol ........................... ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP, SMTP
Program control ............................. Extron's control/configuration program for Windows
General
Power ............................................. 100 VAC to 240 VAC, 50-60 Hz, 30 watts, internal
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling ........................................... Fan, right to left (as viewed from the front panel)
Rack mount .................................... Yes, with included brackets
Enclosure type .............................. Metal
Enclosure dimensions .................. 3.4" H x 17.5" W x 12.0" D (2U high, 1 rack wide)
Product weight .............................. 8.5 lbs (3.9 kg)
Shipping weight ........................... 18 lbs (9 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ................................... CE, CUL, UL
EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI
Environmental ................... Complies with the appropriate requirements of WEEE.
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
TTL: 5.0 Vp-p, unterminated for RGBHV, RGBS
(1) RS-232, 2.5 mm stereo mini jack
RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = TX+
Extron's Simple Instruction Set (SIS
Microsoft
®
Internet Explorer, Telnet
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(8.6 cm H x 44.5 cm W x 30.5 cm D)
(Depth excludes connectors and knobs. Width excludes rack ears.)
MGP 464 • Specifications, Part Numbers, and Accessories
®
)
™
A-3
