ETC User Guide
QuickTouch Preset Handheld
Hardware
The QuickTouch Preset Handheld controller is
controlled using the following hardware features:
Touchscreen: Provides selection and configuration
options from the available screens.
E-stop button: Used to stop all movement in the
system when necessary.
Joystick: Provides a switch to control the velocity
of manual moves and the speed of target moves.
Deadman trigger: Closes the Deadman circuit
and, when depressed, allows for motor movement.
Login
To log in to your controller, press Login from the
main screen. When the User Login dialog appears,
select the appropriate user login from the list. This
causes the Enter Pin Code dialog to appear. Enter
your user code and press Ok to log in.
QuickTouch Preset Handheld
Joystick
Page 4 of 15
E-stop button
Touchscreen
Deadman trigger
