61200226L1-1C
May 2000
ATLAS 800
User Manual
Part Number 1200226L1
Part Number 1200228L1
PLUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATLAS 800 PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for ADTRAN ATLAS 800 PLUS

Summary of Contents for ADTRAN ATLAS 800 PLUS

  • Page 1 PLUS ATLAS 800 User Manual Part Number 1200226L1 Part Number 1200228L1 61200226L1-1C May 2000...
  • Page 2 DMS 100 is a registered trademark of Northern Telecom. 5ESS is a registered trademark of AT&T. AT&T is a registered trademark. 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 (256) 963-8000 © 2000 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A.
  • Page 3 If they do, you will be given advance notice to give you an opportunity to maintain uninterrupted service. If you experience trouble with this equipment (ATLAS), please contact ADTRAN at (256) 963-8000 for repair/ warranty information. The telephone company may ask you to disconnect this equip- ment from the network until the problem has been corrected or until you are sure the equipment is not malfunctioning.
  • Page 4 Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Affidavit Requirements for Connection to Digital Services • An affidavit is required to be given to the telephone company whenever digital terminal equipment without encoded analog content and billing protection is used to transmit digital signals contain- ing encoded analog content which are intended for eventual conversion into voiceband analog sig- nals and transmitted on the network.
  • Page 6 Affidavit for Connection of Customer Premises Equipment to 1.544 Mbps and/or Subrate Digital Services For the work to be performed in the certified territory of ________________________(telco name) State of ________________ County of ________________ I, _____________________________ (name), __________________________________(business address), ____________________ (telephone number) being duly sworn, state: I have responsibility for the operation and maintenance of the terminal equipment to be connected to 1.544 Mbps and/or ________ subrate digital services.
  • Page 7 I agree to provide ______________________ (telco’s name) with proper documentation to demonstrate compliance with the information as provided in the preceding paragraph, if so requested. _________________________________Signature _________________________________Title _________________________________ Date Transcribed and sworn to before me This ________ day of ________, 199___ _________________________________ Notary Public My commission expires:...
  • Page 8 Canadian Equipment Limitations The Industry Canada Certification label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facil- ities of the local telecommunications company.
  • Page 9 Customer or a third party (including, but not limited to, loss of data or information, loss of profits, or loss of use). ADTRAN is not liable for damages for any cause whatsoever (whether based in contract, tort, or otherwise) in excess of the amount paid for the item.
  • Page 10 PLUS • Chapter 12, SNMP Management, describes how to control the ATLAS 800 via SNMP. • Chapter 13, ADTRAN Utilities, describes the SysLog, Telnet, VT-100, and TFTP Server programs de- PLUS livered with the ATLAS 800 Appendices PLUS •...
  • Page 11 Notes provide additional useful information. Cautions signify information that could prevent service interruptions. Warnings provide information that could prevent damage to the equipment or endangerment to human life.

  • Page 13: Table Of Contents

    ATLAS 800PLUS Base Unit ......................... 1-1 ATLAS 800PLUS Features ........................... 1-6 Chapter 2 Installing the ATLAS 800PLUS .................... 2-1 Inspect the ADTRAN Shipment ......................... 2-1 Contents of ADTRAN Shipments....................... 2-1 Check the Power Connection ........................2-1 AC Powered Unit............................ 2-2 DC Powered Unit............................
  • Page 14 Table of Contents Submenus ............................... 4-7 Sub-submenus ..........................4-7 Status................................4-7 S0 System ..............................4-7 Ethernet Status ..........................4-7 Chain Port Status ........................... 4-7 S1—S8 ..............................4-7 Config................................4-7 S0 System ..............................4-7 Ethernet ............................4-8 Chain Port ............................4-8 S1—S8 ..............................
  • Page 15 Table of Contents Serial Number ............................6-3 Boot ROM Rev ............................6-3 System Status ..............................6-3 Event Log ..............................6-4 Clear System Event Log ........................6-4 Ethernet Port ............................6-5 Clear System LED ..........................6-5 System Alarms ............................6-5 System Timing Source ...........................6-5 Resource Usage ............................6-5 Data Tables .............................6-5 Configuration ............................6-6 Trunk Usage ............................6-6 Data Tables .............................6-6...
  • Page 16 Table of Contents TXINIT Timer ..........................6-12 TXFA Timer ..........................6-12 TXADD01 Timer .......................... 6-12 TXDEQ Timer ..........................6-12 TANULL Timer ..........................6-12 TCID Timer ........................... 6-13 Call Stagger ........................... 6-13 System Utility ............................. 6-13 Update Firmware ..........................6-13 Module Slot ........................... 6-14 Module Type ..........................
  • Page 17 Table of Contents Test ................................7-2 State ................................7-2 Status ...............................7-3 Rev ................................7-3 Modules (Quad T1/PRI) Menu ......................7-3 Controller Info ..........................7-3 Alarm Status ............................7-3 DS0 Status ............................7-4 DS0 Alarms ............................7-4 Sig Status ............................7-4 Performance: Current ........................7-5 Performance: 15 Min ........................7-5 Performance: 24 Hr.........................7-5 Configuration ..........................7-5 Test ..............................7-6 Chapter 8 Dedicated Maps Terminal Menu ..................
  • Page 18 Table of Contents Source ID ..............................9-3 Outdial Number ............................ 9-3 Force Mode ............................9-3 Backup Criteria ............................9-3 Restore Criteria ............................9-3 Startup Delay ............................9-3 Backup Delay ............................9-3 Restore Delay ............................9-4 Max Num Redials ..........................9-4 Redial Timer ............................
  • Page 19 Table of Contents Global Param ............................... 10-8 End of Number Timeout ........................10-8 Area Code .............................10-8 Nbr Complete Templates ........................10-8 Number Type Templates ........................10-8 Automatic Routeback Rejection ......................10-9 Quad T1/PRI Module Interface Configuration..................10-9 Quad T1/PRI Module (Network Termination/PRI)............... 10-9 Switch Type ...........................10-9 First DS0 ............................10-9 Number of DS0s ..........................10-10 Outgoing Number Conversion ....................10-10...
  • Page 20 Configuring a Trap Destination List via Terminal Menu ...............12-2 Filtering (Disabling) Traps........................12-2 Standard Traps ..........................12-3 DS1 Traps ............................12-3 DS1 Alarm Traps.......................... 12-3 DS1 Alert Traps..........................12-4 Chapter 13 ADTRAN Utilities........................13-1 Overview ..............................13-1 SysLog Host Daemon ..........................13-1 SysLog GUI ............................13-2 Monitor............................13-2 Menu Bar ..............................13-3 File ................................
  • Page 21 Table of Contents Clear Red Events ..........................13-4 Help................................13-4 Telnet Utility ..............................13-4 Session Menu ............................... 13-6 Connect ..............................13-6 Host Name .............................13-6 Port ..............................13-6 Edit Entry ............................13-6 Add New ............................13-6 Delete ..............................13-6 Connect ............................13-6 Disconnect .............................13-6 Transfer Cfg ............................13-7 Exit .................................13-7 Edit Menu..............................
  • Page 22 Table of Contents Disable ..............................13-11 Abort ..............................13-11 Exit ............................... 13-11 Print Log ..............................13-11 ...to Clipboard ............................ 13-11 ...to Printer ............................13-11 Clear Log ............................13-11 Help................................13-12 Contents .............................. 13-12 About ..............................13-12 Status Field ..............................13-12 Meter Field ..............................

  • Page 23: List Of Figures

    List of Figures Figure 1-1. Point-to-Point Circuit......................1-2 Figure 1-2. Frame Relay Circuit ........................ 1-3 Figure 1-3. Digital Access Cross-Connect System (DACS) ..............1-4 Figure 1-4. T1 Bandwidth Management ....................1-5 Figure 1-5. WAN Overbooking ......................... 1-6 PLUS Figure 2-1. AC Powered ATLAS 800 Rear Panel ................
  • Page 24 List of Figures Figure 13-2. SysLog Menu Tree for the Menu Bar.................. 13-3 Figure 13-3. Telnet Menu Tree........................13-5 Figure 13-4. VT-100 Menu Tree ......................... 13-8 Figure 13-5. TFTP Server Interface Menu Tree ..................13-10 Figure 13-6. TFTP Server Interface......................13-11 PLUS xxiv ATLAS 800...
  • Page 25 List of Tables Table 2-1. Control/Chain In Pinout......................2-5 Table 2-2. Control/Chain Out Pinout..................... 2-5 Table 2-3. Network Pinout ........................2-6 Table 2-4. Ethernet 10BaseT Pinout ......................2-7 PLUS Table 4-1. ATLAS 800 Front Panel Description ................4-2 Table 4-2. LED Descriptions........................
  • Page 26 List of Tables PLUS xxvi ATLAS 800 User Manual 61200226L1-1...

  • Page 27: Product Overview

    Introducing the ATLAS 800 PLUS Chapter 1 PRODUCT OVERVIEW PLUS The ATLAS 800 is a modular, highly scalable platform that provides ro- bust solutions for the wide area communication needs of medium-to-large corporations and network access providers. ATLAS is an Integrated Access System with the most extensive support of dedicated bandwidth manage- ment and access switching in the industry.

  • Page 28: Figure 1-1. Point-To-Point Circuit

    Chapter 1. Introducing the ATLAS 800PLUS The modules include the following: • Quad Nx 56/64 Module • Quad T1/PRI Module • Octal Basic Rate ISDN Module • T3 Module • Async-232 Module • Modem-16 Module Frame Relay Frame relay is a packet-switched service that allows efficient transfer of bursty traffic in a WAN environment.

  • Page 29: Figure 1-2. Frame Relay Circuit

    Chapter 1. Introducing the ATLAS 800PLUS Frac T1 Frame Relay Figure 1-2. Frame Relay Circuit The Frame Relay/Router upgrade option adds the capability for the ATLAS series of Integrated Access Devices to act as a voice/data FRAD, a frame re- lay switch, and an IP router in addition to the current available bandwidth manager and switch applications.

  • Page 30: Figure 1-3. Digital Access Cross-Connect System (Dacs)

    Windows -based GUI management system can allow end-to-end management with downstream ADTRAN T1 products. User configurations can be preserved in non-volatile memory and duplicated for managing multiple ATLAS implementations. ATLAS also supports FLASH upgrades for future enhancements. You can remotely download software using TFTP or XMODEM.

  • Page 31: Figure 1-4. T1 Bandwidth Management

    ATLAS is ideal for point-to-point configurations or access to public networks. For optimization of existing equipment and network re- sources, ATLAS can be paired with ADTRAN’s TSU product offerings to support a variety of data and analog voice applications (see Figure 1-4).

  • Page 32: Atlas 800Plus Features

    FEATURES Configuration and Management • VT 100 Emulation • T-Watch PRO, Microsoft Windows based GUI • SNMP, per MIB II (RFC1213), DS1 MIB (RFC1406), and ADTRAN pri- vate MIBs • Telnet • LCD Front Panel • Six levels of password protection and privileges Software Upgrade •...
  • Page 33 Chapter 1. Introducing the ATLAS 800PLUS Dedicated Connection Maps • Up to five connection maps • Time of day/day of week configurable • Preserves signaling through cross-connect • No effect on non-configured channels Switched Connection Maps • Inbound and outbound call filtering and blocking Testing •...
  • Page 34 Chapter 1. Introducing the ATLAS 800PLUS PLUS ATLAS 800 User Manual 61200226L1-1...

  • Page 35: Inspect The Adtran Shipment

    , carefully inspect the ATLAS 800 Base Unit for shipping damage. If you suspect damage, file a claim immedi- ately with the carrier and then contact ADTRAN Technical Support (see Warranty and Technical Support Information on page C-1). If possible, keep the...

  • Page 36: Ac Powered Unit

    Chapter 2. Installing the ATLAS 800PLUS AC Powered Unit PLUS The AC powered ATLAS 800 (P/N 1200226L1) comes equipped with a detachable 8-foot power cord with a three-prong plug for connecting to a grounded power receptacle. PLUS Power to the ATLAS 800 must be from a grounded 115 V AC, 60 Hz or 220 V AC, 50-60 Hz source.

  • Page 37: Review The Rear Panel Design

    Chapter 2. Installing the ATLAS 800PLUS The supplementary equipment grounding conductor shall not be smaller in size than the ungrounded branch-circuit supply conductors. The supple- mentary equipment grounding conductor shall be connected to the product at the terminal provided, and shall be connected to ground in a manner that will retain the ground connection when the product is unplugged from the receptacle.

  • Page 38: Control/Chain In Port

    Chapter 2. Installing the ATLAS 800PLUS NTWK1 Control/Chain Out RJ-48C Connec- Connects to Chain tion Port In of another unit 10 Base T MON (Monitor) NTWK2 Control/ Bantam test jack RJ-48C Connection RJ-48C Connec- Chain In tion Port Port Interface of Power Switch Chain In CAUTION: MAINTENANCE TO BE PERFORMED BY TRAINED SERVICE PERSONNEL ONLY...

  • Page 39: Control/Chain Out Port

    Chapter 2. Installing the ATLAS 800PLUS Table 2-1. Control/Chain In Pinout NAME DESCRIPTION Ground - connected to unit chassis Request to send - flow control RXDATA PLUS Data received by the ATLAS 800 Data terminal ready TXDATA PLUS Date transmitted by the ATLAS 800 Carrier detect UNUSED —...

  • Page 40: Network Connection

    Chapter 2. Installing the ATLAS 800PLUS Table 2-2. Control/Chain Out Pinout (Continued) NAME DESCRIPTION RX DATA Data received from chained units by the ATLAS. Connect to TX DATA of the next unit (Chain In pin 5). 6,7,8 UNUSED — Network Connection The two eight-pin modular jacks labeled NTWK 1 and NTWK 2 provide the network connection.

  • Page 41: Ethernet 10Baset Connection

    Chapter 2. Installing the ATLAS 800PLUS Ethernet 10BaseT Connection The 10BaseT Ethernet port (RJ-48C) provides an Ethernet LAN connection, which is used for TFTP, SNMP, and Telnet connection. Connection The network connection follows, with the pinout shown in Table 2-4. Connector type (USOC) RJ-48C Part number...

  • Page 42: Install Any Option Modules

    Chapter 2. Installing the ATLAS 800PLUS SLOT 1 SLOT 5 SLOT 2 SLOT 6 SLOT 7 SLOT 3 SLOT 8 SLOT 4 PLUS Figure 2-3. ATLAS 800 Slot Designation (Rear View) INSTALL ANY OPTION MODULES PLUS After installing the base ATLAS 800 Base Unit and connecting the re- quired cables, you can install your choice of option modules.

  • Page 43: Figure 3-1. Front Panel Lcd

    Operating the ATLAS 800 PLUS Chapter 3 PLUS METHODS OF OPERATING THE ATLAS 800 PLUS You can access basic setup functions from the ATLAS 800 Front Panel. PLUS However, to access all of the ATLAS 800 functions, set up a Telnet ses- sion or use a VT-100 terminal emulation.

  • Page 44: Chapter 3 Operating The Atlas 800Plus

    To receive the full benefit of the terminal menu interface, you should use a fully VT-100 compatible client. The ADTRAN Utilities flop- py disks (that you can install on a PC) contain both a VT-100 client and a cus- tomized Telnet program.

  • Page 45: Using Telnet

    Chapter 3. Operating the ATLAS 800PLUS Using Telnet PLUS To connect to the ATLAS 800 via Telnet, define the IP address, set the subnet mask, and, typically, wet the default gateway IP address. The follow- ing Step/Action tables provide instructions for performing these tasks. You must define the IP address before attempting to connect via Telnet.

  • Page 46: Starting A Telnet Session

    Chapter 3. Operating the ATLAS 800PLUS Instructions for Setting the Gateway IP Address Step Action From the Front Panel, select 2) CONFIG , then S0) SYSTEM , then 1) ETHERNET . When the submenu displays, select 3) DEF GATEWAY . Enter the default gateway by entering each number followed by Enter to move to the next field.

  • Page 47: Using T-Watch Pro

    See Access Passwords on page 6-11 for details. Using T-Watch PRO T-Watch PRO is the ADTRAN Microsoft Windows management software program designed to control TSU units from a remote PC. It provides limit- PLUS...
  • Page 48 Chapter 3. Operating the ATLAS 800PLUS PLUS ATLAS 800 User Manual 61200226L1-1...
  • Page 49 Using the Front Panel Chapter 4 Use the Front Panel to select and set up the method of connectivity for con- PLUS trolling the ATLAS 800 Base Unit and to monitor the operation and sta- tus of the Base Unit. Figure 4-1 identifies the display panels and the operation keys located on the Front Panel.

  • Page 50: Chapter 4 Using The Front Panel

    Chapter 4. Using the Front Panel PLUS Table 4-1. ATLAS 800 Front Panel Description Feature Description LCD Window Displays menu items and messages in two lines by sixteen characters in a backlit liquid crystal display (LCD). It also displays alarm and status information.

  • Page 51: Table 4-2. Led Descriptions

    Chapter 4. Using the Front Panel Table 4-2. LED Descriptions For these LEDs... This color light... Indicates that... System Green (solid) No diagnosed system faults were found. Green (fast blink) Flash download is in progress. Yellow (solid) Fault was diagnosed, but the condition no longer exists.

  • Page 52: Operation Keys

    Chapter 4. Using the Front Panel OPERATION KEYS Operation keys are ATLAS 800 Front Panel keys that perform alternate func- tions. To activate an operation key, simultaneously press the Front Panel Shift key and the operation key that you want to activate, as shown in Table 4-3.
  • Page 53 Chapter 4. Using the Front Panel Selecting Front Panel Menus To do this... Go to this menu... See also page... STATUS PLUS Display the status of the ATLAS 800 STATUS Display the card type in each slot CONFIG PLUS Perform limited configuration of the ATLAS 800 UTIL Monitor and modify miscellaneous settings ALRM...

  • Page 54: Front Panel Main Menu

    Chapter 4. Using the Front Panel Editing a Data Field (Continued) Step Action Select another data field to edit, or press Cancel to return to the submenu. Pressing Cancel prior to pressing Enter voids any data changes. The original data value is restored and the cursor returns to the submenu field.

  • Page 55: Menus

    Chapter 4. Using the Front Panel To help you follow the terminal menu hierarchy, the following notations are used. MENUS > » Submenus »» Sub-submenus STATUS PLUS > The Status menu branch lets you view the status of the ATLAS 800 Base Unit and any installed modules.

  • Page 56: Ethernet

    Chapter 4. Using the Front Panel »» Ethernet Allows you to create and change configuration settings for the 10BaseT Ethernet connection. IP Address PLUS Uniquely identifies the ATLAS 800 on a TCP/IP network. This address is composed of four decimal num- bers, each in the range of 0 to 255, separated by periods.

  • Page 57: S1-S8

    Chapter 4. Using the Front Panel Unit ID Accesses the current Unit ID setting, which is the system identifier used for ADTRAN Data Link Layer Protocol (ADLP) configuration control (such as using T-Watch PRO). Editing or changing the Unit ID requires the use of a passcode if a passcode is defined.

  • Page 58: Selftest

    Chapter 4. Using the Front Panel » Selftest Executes a system self-test, and the LCD displays the Pass or Fail when the test is complete. Options include Run Selftest, Show Results, and Clear Re- sults. The Selftest option disrupts data flow. »»...

  • Page 59: Clear Results

    Password Reset option. When you se- lect this option, two items display in the LCD window: CHALLENGE # and RESPONSE #. Call ADTRAN technical support, and tell them the challenge number. They use this to generate a random response number. Enter this response number PLUS...

  • Page 60: View History

    Chapter 4. Using the Front Panel » View History Displays a time and date-stamped list of the alarms that have occurred in the PLUS ATLAS 800 . Some alarm types include -A to indicate the alarm is active and -I to indicate the alarm is inactive. »...

  • Page 61: Chapter 5 Navigating The Terminal Menu

    Navigating the Terminal Menu Chapter 5 TERMINAL MENU WINDOW PLUS The ATLAS 800 uses a multilevel menu structure that contains both menu items and data fields. All menu items and data fields display in the terminal menu window, through which you have complete control of the PLUS ATLAS 800 (see Figure 5-1).

  • Page 62: Window Panes

    Chapter 5. Navigating the Terminal Menu Window Panes When you first start a terminal menu session, the terminal menu window is divided into left and right panes. The left pane shows the list of available submenus, while the right pane shows the contents of the currently selected submenu.

  • Page 63: Additional Terminal Menu Window Features

    Chapter 5. Navigating the Terminal Menu Additional Terminal Menu Window Features Describes the status of the ATLAS base unit (system). Tool Tip Provides a brief description of the currently selected (highlighted) command. Port Status Displays status information, such as OK, WARN, or ALRM, about ports 1—8.

  • Page 64: Session Management Keystrokes

    Chapter 5. Navigating the Terminal Menu Move to the bottom of a screen. Ascend one menu level. Backspace Session Management Keystrokes To do this... Press this... Ctrl-L Log out of a session. Invalidate the password entry and return to the login screen. Ctrl-S Refresh the screen.

  • Page 65: Getting Help

    Chapter 5. Navigating the Terminal Menu To do this... Press this key... Paste the item stored in the clipboard, if the information is compatible. You must confirm all pastes—except those to a single editable field. > Increment the value of certain types of fields by one when you paste information into those fields.
  • Page 66 Chapter 5. Navigating the Terminal Menu PLUS ATLAS 800 User Manual 61200226L1-1...
  • Page 67 Terminal Menu and System Chapter 6 Control SELECTING THE APPROPRIATE MENU The terminal menu is the access point to all other operations. Each terminal menu item has several functions and submenus that identify and provide ac- cess to specific operations and parameters. Use the chart below to help you select the appropriate terminal menu.

  • Page 68: Chapter 6 Terminal Menu And System Control

    Chapter 6. Terminal Menu and System Control SECURITY LEVELS To edit terminal menu items, you must have a password and the appropriate security level. Table 6-1 describes the six security levels. See Access Passwords on page 6-11 for additional information on working with passwords. Table 6-1.

  • Page 69: System Name

    Chapter 6. Terminal Menu and System Control » System Name Security level: 3; Read security: 5 PLUS Provides a user-configurable text string for the name of the ATLAS 800 This name can help you distinguish between different installations. You can enter up to 40 alpha-numeric characters in this field, including spaces and special characters (such as an underbar).

  • Page 70: Event Log

    Chapter 6. Terminal Menu and System Control Figure 6-2. System Status Menu » Event Log Read security: 5 Displays the last 350 warning or failure messages sent—including the day, date, and priority of the message. The most recent messages display at the top of the list.

  • Page 71: Ethernet Port

    Chapter 6. Terminal Menu and System Control » Ethernet Port Read security: 5 Displays status information about the Ethernet port. An asterisk (*) indi- cates activity for the item. The following read-only fields are available to review: I/F Status Indicates the current status of the 10BaseT port. Tx Frames Indicates the number of frames transmitted from the 10BaseT port since system startup.

  • Page 72: Configuration

    Chapter 6. Terminal Menu and System Control 0 (zero) available Provides a count of the number of times the quantity of available resources reached 0. Hour Data Shows availability information by hour for a 24-hour period. Reset Activates the reset of all accumulated availability sta- tistics.

  • Page 73: Chain Port Tx Bytes

    » ADLP Address Write security: 2; Read security: 5 Shows the system ADTRAN Data Link Layer Protocol (ADLP) address for connecting remote devices to management software (such as T-Watch PRO). The allowable range is between 2 and 65520. Enter a value not used by any of the TSU units controlled by the management software.

  • Page 74: Session Timeout

    Chapter 6. Terminal Menu and System Control » Session Timeout Write security: 3; Read security: 5 Defines the number of seconds the terminal session must remain idle before the session times out. You can enter zero to deactivate this option (the ses- sion will never time out).

  • Page 75: Port Type

    Chapter 6. Terminal Menu and System Control »» Port Type Write security: 2; Read security: 5 Specifies whether you use Direct Dial mode. »» Port Speed Write security: 2; Read security: 5 Specifies the baud rate of the port. Select either 2400, 9600, 19200, or 38400. If you are using for Port Type , ensure that the Port Speed setting Dial...

  • Page 76: Traps Destination

    Write security: 3; Read security: 5 Configures the ATLAS Syslog client for use with a Syslog server (supplied on ADTRAN /Utility disk or available on most UNIX platforms). »» Transmission Enables or disables the transmission of log events to the external Syslog server.

  • Page 77: Access Passwords

    If you lose or forget the ATLAS 800 system administrator password, contact ADTRAN technical support for help in resetting the password. In order to reset the password, you must have access to the front panel. For details on resetting the password, see Password Reset on page 1-30.

  • Page 78: Active

    Chapter 6. Terminal Menu and System Control Instructions for Changing Passwords Step Action Select the Password field—a new Password field displays. Type the new password in the Enter field. Type the new password again in the Confirm field. The password can contain up to 12 alphanumeric characters. You can also use spaces and special characters in the password.

  • Page 79: Tcid Timer

    Chapter 6. Terminal Menu and System Control »» TCID Timer Write security: 3; Read security: 5 Specifies the length of time both endpoints attempt to negotiate an agree- able value for bearer channels and channel capacities before deciding the BONDING call has failed. »»...

  • Page 80: Module Type

    Chapter 6. Terminal Menu and System Control formation on how to update firmware using this method, see TFTP Firmware Updates on page 11-4. The available update options vary depending on whether you select Slot 0 , Slots 1 through 8 , or All Modules of a Type . »»...

  • Page 81: Current Update Status

    Chapter 6. Terminal Menu and System Control Restart at Specified Lets you specify a date and time to automatically Date and Time restart the updated module. (When you select this option, a new field called Restart Date and Time displays below the current field.) Restart Date and Time Write security: 1;...

  • Page 82: Update Status

    ATLAS 800 units. In addition, Config Trans- fer can retrieve a configuration file from a TFTP server. To support these transfers, ADTRAN delivers a TFTP program with PLUS ATLAS 800 called TFTP Server. You can configure any PC running Mi- crosoft Windows with this software, and store a configuration file.

  • Page 83: Load And Use Config

    TFTP Server IP Address . » System Utilization Write security: 0; Read security: 0 Displays statistics related to the ATLAS internal operating system. Please check with ADTRAN Technical Support before attempting to use this menu. » System Selftest Write security: 3; Read security: 5 Initiates a system self-test.

  • Page 84: Clear Self-Test Log

    Chapter 6. Terminal Menu and System Control Index number of the log Time Time and date of the log entry ATLAS slot number ATLAS port number Event Event description Result Shows Pass/Fail results The tests associated with the system controller include the following: This event...

  • Page 85: Ping

    Chapter 6. Terminal Menu and System Control » Ping Write security: 5; Read security: 5 Allows you to send pings (ICMP requests) to devices accessible via the net- work. Only ping one session can be active at a time. »» IP Address Write security: 5;...

  • Page 86: Reboot System

    Chapter 6. Terminal Menu and System Control » Reboot System Write security: 2; Read security: 5 PLUS Reboots the ATLAS 800 . When you select this command, the following message displays: ** Press WARNING ** This will reboot the entire system! to reboot the system, or to exit the command.

  • Page 87: Chapter 7 Modules Terminal Menu

    Modules Terminal Menu Chapter 7 To help you follow the terminal menu hierarchy, the following notations are used. MENUS > » Submenus »» Sub-submenus MODULES > Write security:3; Read security:5 The Modules menu provides options that allow you to configure and con- trol the installed option modules as well as the controller T1/PRI ports.

  • Page 88: Type

    Chapter 7. Modules Terminal Menu » Type Write security:3; Read security:5 Displays the type of module actually installed in the slot or the type of PLUS module you plan to install in the slot. The ATLAS 800 automatically detects the type of module installed in each slot, and the field automat- Type ically defaults to the installed module type.

  • Page 89: Status

    Chapter 7. Modules Terminal Menu » Status Read security:5 PLUS Displays status information on the ATLAS 800 T1/PRI ports and other installed modules as follows: Online The module is enabled and is responding to the system controller’s status polls. This is the normal response of the system.

  • Page 90: Ds0 Status

    Chapter 7. Modules Terminal Menu Port number displayed. Loss of Signal No signal detected on port interface. (LOS) Red Alarm Not able to frame data received on the port. Alternate- (RED) ly referred to as Out of Frame (OOF). Yellow Alarm Remote alarm indicator (RAI) being received on port.

  • Page 91: Performance: 15 Min

    Chapter 7. Modules Terminal Menu »» Performance: Write security:4; Read security:5 Current The performance fields – either current, 15 minute total, or 24 hour total – provide status on key performance measures as specified in ANSI T1.403 and AT&T TR54016 for each of the four T1/PRI ports as follows: Displays the port number.

  • Page 92: Test

    Chapter 7. Modules Terminal Menu Code Write security:2; Read security:5 Matches the line code of the circuit to which it is connected (available from the network supplier). Tx Yellow Write security:3; Read security:5 (Auto Tx Yellow Alarm) Enables and disables the transmit- ting of yellow alarms.
  • Page 93 Chapter 7. Modules Terminal Menu Remote LB Write security:4; Read security:5 (Remote Loopback) Sends a loopback code to a remote CSU. ANSI FDL Line (Requires ESF mode) ANSI FDL Pyld (Requires ESF mode) AT1 Inband line Pattern Write security:4; Read security:5 Specifies the test pattern to be transmitted out the port.
  • Page 94 Chapter 7. Modules Terminal Menu PLUS ATLAS 800 User Manual 61200226L1-1...

  • Page 95: Chapter 8 Dedicated Maps Terminal Menu

    Dedicated Maps Terminal Chapter 8 Menu OVERVIEW The Dedicated Maps menu assigns dedicated connections between any two PLUS ports in the ATLAS 800 Base Unit. This chapter describes the Dedicated Maps menu items (see Figure 8-1). In addition, step-by-step instructions are provided for setting up a sample dedicated map (see Creating A Dedicated Map on page 8-6).

  • Page 96: Activate Map

    Chapter 8. Dedicated Maps Terminal Menu ACTIVATE > Write security:3; Read security:5 Activates a dedicated map—automatically or manually. You can have up to five different dedicated maps, each with an optionally specified name. » Auto Automatically activates a particular dedicated map at the time and day specified in Activate Time (see Activate Time on page 8-5).

  • Page 97: From Slt

    Chapter 8. Dedicated Maps Terminal Menu »» # (Index Number) Displays the number of the dedicated map connection. If PLUS you press in this field, ATLAS 800 adds another dedicated map con- nection, numbered consecutively. »» FROM Slt Write security:3; Read security:5 (From Slot) Specifies the slot to use for the FROM connection.
  • Page 98 Chapter 8. Dedicated Maps Terminal Menu This DS0 is already used in this Dedicated Map. This DS0 is already used in this Dedicated Map and conflicts with this connection. Data Rate Write security:3; Read security:5 Defines the data rate per DS0. If FROM Slt is an Nx port, the data rate per DS0 must be set.

  • Page 99: To Config

    Chapter 8. Dedicated Maps Terminal Menu »» To Config Security level: 3; Read security: 5 Specifies the configuration for the To connection. The selections that dis- play in this field are based on the type of module selected in the TO Slot option.

  • Page 100: Designing A Dedicated Map

    Chapter 8. Dedicated Maps Terminal Menu ATLAS 800 T1-C T1-A T1-B Figure 8-2. Trunk Conditioning Example: Creating A Dedicated Map A Dedicated Map defines connections for dedicated bandwidth between ports, and grooms and cross-connects bandwidth between T1 ports. Any ATLAS port supporting dedicated bandwidth can be mapped to any other port supporting dedicated bandwidth (see the example in Figure 8-3).

  • Page 101: Configuring The Ports

    Chapter 8. Dedicated Maps Terminal Menu step-by-step procedures for creating a sample Dedicated Map based on the connections and ports given in Table 8-1. Table 8-1. Connections and Ports PLUS PLUS Name DS0s Name DS0s ATLAS 800 Port ATLAS 800 Port Controller T1 9-24...

  • Page 102: Defining The Connections

    Chapter 8. Dedicated Maps Terminal Menu Figure 8-4. Slot 0 Module Configuration Menu Defining the Connections Begin by navigating to Dedicated Maps / Create/Edit Maps and naming your map. Navigate to Dedicated Maps / Connects . The Connects submenu defines the connections necessary to route the required bandwidth.
  • Page 103 Chapter 8. Dedicated Maps Terminal Menu Instructions for Defining Data Connections (Continued) Step Action Paste this information onto a new connection line by positioning the cursor over the index numbers of the new connections, and pressing Modify these connection lines to complete the connections for data.

  • Page 104: Figure 8-5. Completed Dedicated Map

    Chapter 8. Dedicated Maps Terminal Menu Figure 8-5. Completed Dedicated Map PLUS 8-10 ATLAS 800 User Manual 61200226L1-1...

  • Page 105: Chapter 9 Dedicated Circuit Backup And Circuit Status

    When the ATLAS loses communication with the remote site, backup will be initiated. This feature is compatible with the Inband Mode of the ADTRAN TSU series of products. Currently, dedicated circuit backup is supported only for Nx interfaces (V.35 or USSI) nailed to T1s.

  • Page 106: Configuration

    Chapter 9. Dedicated Circuit Backup and Circuit Status Configuration First, configure your dedicated maps normally. Refer to Chapter 8 for more information on configuring Dedicated Maps. One thing to remember is that the endpoint receiving the backup data (i.e., the Nx endpoint) needs to be in the From column.

  • Page 107: Interface Configuration

    Chapter 9. Dedicated Circuit Backup and Circuit Status INTERFACE CONFIGURATION > » Originate/Answer The following selections are available for the Originate/Answer menu item. Originate The endpoint will originate the backup call. Answer The endpoint will answer any incoming calls, but will only go into backup if an error is detected.

  • Page 108: Restore Delay

    Chapter 9. Dedicated Circuit Backup and Circuit Status » Restore Delay This only applies to originating endpoints. The amount of time to delay after clearing an alarm before coming out of backup. If the circuit goes into alarm before this time has expired, the endpoint will remain in backup. »...

  • Page 109: Circuit Status Menu

    Chapter 9. Dedicated Circuit Backup and Circuit Status CIRCUIT STATUS MENU The Circuit Status menu allows the user to view at a glance the status of any circuits that are configured for dedicated circuit backup. Figure 9-3 shows the Circuit Status menu. Figure 9-3.

  • Page 110: Bkup Status (Backup Status)

    Chapter 9. Dedicated Circuit Backup and Circuit Status BKUP STATUS > String indicates the current status of the dedicated line. The following selec- (BACKUP tions are available for the Backup Status menu item. STATUS) Backup is forced through the interface menu. Restoral is forced through the interface menu.

  • Page 111: Test

    Chapter 9. Dedicated Circuit Backup and Circuit Status TEST > This only displays if an endpoint is configured for Originate. This submenu is used to monitor regular test call status for the backup endpoint. The record label displays the number of successful tests and the number of test failures, respectively.
  • Page 112 Chapter 9. Dedicated Circuit Backup and Circuit Status PLUS ATLAS 800 User Manual 61200226L1-1...

  • Page 113: Chapter 10 Dial Plan Terminal Menu

    Dial Plan Terminal Menu Chapter 10 OVERVIEW The Dial Plan submenus (see Figure 10-1) set global ATLAS switch parame- ters as well as individual parameters for each ATLAS port handling a switched call. The individual ports are separated into two port types: net- work and user.

  • Page 114: Figure 10-2. Dial Plan Menu Tree

    Chapter 10. Dial Plan Terminal Menu Slot/Svc Src ID Port/PEP Accept Number Search Network Term Out # Accept Data 64K Data 56K Reject Number Out#Rej Data 64K Data 56K Audio Speech Ifce Config These submenus vary depending on the Module. Slot/Svc Port/PEP Src ID...

  • Page 115: Network Term

    Chapter 10. Dial Plan Terminal Menu NETWORK > This menu allows the user to define option parameters for ports which ter- TERM minate a connection from the Network (PSTN). In applications where two ATLAS units are used in a point-to- point configuration, a port in the ATLAS at one end would act as the Network (User Termination), while the ATLAS at the opposite end would be terminating a “Network”...

  • Page 116: Accept Numbers

    Chapter 10. Dial Plan Terminal Menu »» Accept Numbers This field designates which numbers this end point will pass on toward the Network (PSTN). The accept list may consist of multiple entries. The num- bers are defined using “wild cards”: Any single digit N = Any single digit 2—9 $ = Any number of digits of any value...

  • Page 117: Reject Number

    Chapter 10. Dial Plan Terminal Menu »» Reject Number This field identifies which numbers this end point will not pass on toward the Network (PSTN). The reject list may consist of multiple entries. The reject list may be used to more easily specify the call filtering desired. The “wild cards”...

  • Page 118: In#Accept

    Chapter 10. Dial Plan Terminal Menu » In#Accept Write security: 3; Read security: 5 This submenu defines the parameters for incoming calls that PLUS ATLAS 800 will accept from the Network. »» Source ID Write Security: 3 Read Security: 5 This field identifies the ID of the call sources that this endpoint will accept calls from.

  • Page 119: Data 64K, Data 56K

    Chapter 10. Dial Plan Terminal Menu Primary The Search parameter instructs ATLAS which order to Search search for an accept number match. Normally all searches are set to Primary. The Secondary search selection would be used to force ATLAS to only accept a call at this end point if all Primary end points were unavailable.

  • Page 120: Global Param

    Chapter 10. Dial Plan Terminal Menu GLOBAL > Set ATLAS options which apply to all switched operations, both incoming PARAM and outgoing calls. » End of Number Write security: 3; Read security: 5 Timeout This parameter sets the length of time ATLAS will wait before assuming the outgoing dialed number is complete.

  • Page 121: Automatic Routeback Rejection

    Chapter 10. Dial Plan Terminal Menu » Automatic Routeback Denotes an Entry Number (MAX 50). Press INS/DEL to in- Rejection sert/delete any entry. Prefix Sets the prefix for the number type. Only digits 0 and 1 are allowed (MAX 6). Pattern Modifies an entry when you press Enter (MAX 40).

  • Page 122: Number Of Ds0S

    Chapter 10. Dial Plan Terminal Menu »» Number of DS0s Write Security: 3 Read Security: 5 Defines the number of DS0s used for calls on this PRI. DS0 24 is assumed to be used by the PRI for the D channel. »»...

  • Page 123: Outgoing Caller Id

    Chapter 10. Dial Plan Terminal Menu would almost always be correct. If less than All digits are sent, then the prefix is defined below. »» Outgoing Caller ID Write Security: 3 Read Security: 5 Inserts a called ID based on the following selections. Send as ATLAS forwards whatever ID it receives (including None).

  • Page 124: Quad T1/Pri Module (Network Termination/Rbs)

    Chapter 10. Dial Plan Terminal Menu QUAD T1/PRI MODULE (NETWORK TERMINATION/RBS) When you are working in the Network Termination section of the Dial Plan menu, the Slot is defined as a T1/PRI module, and Sig is set to RBS, the fol- lowing interface configuration options are available: »»...

  • Page 125: Direct Inward Dialing

    Chapter 10. Dial Plan Terminal Menu »» Direct Inward Write security: 3; Read security: 5 Dialing This defines to ATLAS whether or not DID is being used by the Network. If DID is Enabled, then the following information must be defined: DID Digits Write security: 3;...

  • Page 126: Quad T1/Pri Module (User Termination/Pri)

    Chapter 10. Dial Plan Terminal Menu • When creating the Call Accept list, specify a Source ID( s) as well as a dialed number or range of dialed numbers to accept. For example, an application requires that all calls originating from Port 1 of the Quad T1/PRI module in Slot 1 be switched to Port 4 of that same mod- ule.

  • Page 127: Called Digits Transferred

    Chapter 10. Dial Plan Terminal Menu versus data calls. A setting of indicates no special facilities have Normal been subscribed. »» Called Digits Write security: 3; Read security: 5 Transferred Defines to ATLAS the number of called-number digits to forward. When attached to a PBX, the PBX may be provisioned to expect to receive fewer than all of the called digits of the incoming call.

  • Page 128: Quad T1/Pri Module (User Termination/Rbs)

    Chapter 10. Dial Plan Terminal Menu QUAD T1/PRI MODULE (USER TERMINATION/RBS) When you are working in the User Termination section of the Dial Plan menu, the Slot is defined as a T1/PRI module, and Sig is set to RBS, the fol- lowing configuration options are available: »»...

  • Page 129: Caller Id Number

    Chapter 10. Dial Plan Terminal Menu » Caller ID Number Write security: 3; Read security: 5 Defines the number for ATLAS to use to provide Caller ID to the Network for outgoing calls sent through this end point. This option only displays if Direct Inward Dialing is set to .

  • Page 130: Ports Available

    Chapter 10. Dial Plan Terminal Menu »» Ports Available Indicates which of the four ports of the Quad Nx56/64 module have already been defined either in another switched end point (indicated by “s”) or in a Dedicated Map (indicated by “n”). This field is read-only. »»...
  • Page 131 Chapter 10. Dial Plan Terminal Menu This option allows a selected quantity of the Most Significant Digits (MSD) Phone Number The phone number(s) assigned to this BRI phone line. SPID Number This entry must match the SPID number(s) which have been set in the Network’s ISDN switch (or in the PBX) for this BRI line.

  • Page 132: Source Id

    Chapter 10. Dial Plan Terminal Menu OCTAL BRI MODULE (USER TERMINATION) The Octal BRI with a “U” interface acts as the Network while interfacing to user equipment (terminal adapters). When you are working in the Network Termination section of the Dial Plan menu and the Slot is defined as a UBRI-8 module, the following interface configuration options are available: »»...

  • Page 133: Id Presentation

    Chapter 10. Dial Plan Terminal Menu The following options are only available if Outgoing Caller ID is not set to Send as Provided . »» ID Presentation Specifies the presentation of the caller ID information. »» ID Number This is the substitute number for the caller ID information. CREATING DIAL PLANS—EXAMPLES The ATLAS Dial Plan acts as the numbering plan for switched connections.

  • Page 134: Figure 10-4. Point-To-Point

    Chapter 10. Dial Plan Terminal Menu Example 2 Point-to-Point Connection Dial Plan Configuration In this example, ATLAS A operates as the network while ATLAS B termi- nates the network. That is, ATLAS A emulates the network and its PRI inter- face acts as the user termination.
  • Page 135 Chapter 10. Dial Plan Terminal Menu Instructions for Configuring the Ports for Example 3 Step Action Prior to setting up the Dial Plan, you must configure the Controller T1/PRI interfaces. This configuration action only brings up the T1 transport; set the BRI configuration (SPID and phone number) as part of the Dial Plan.

  • Page 136: Table 10-1. Network And Attached Equipment Provisioning

    Chapter 10. Dial Plan Terminal Menu Table 10-1. Network and Attached Equipment Provisioning Network PRI Type of provided PRI switch National ISDN DMS 100 custom 4ESS custom 5ESS custom DID- number of digits Type of provided BRI switch National ISDN DMS 100 custom 5ESS custom SPID(s) and phone number(s) provisioned for the BRI...

  • Page 137: Table 10-3. User Terminations

    Chapter 10. Dial Plan Terminal Menu Table 10-3. User Terminations NAME PORT INCOMING OUTGOING OTHER ACCEPT # REJECT # BRI type : BRI-D Octal BRI 888-1001 (D); Blank - No called BRI-E Slot 1, 888-1002 (E); number will be 5ESS SPID # to match Video BRI-F Ports 4-5,6 888-1003 (F)
  • Page 138 Chapter 10. Dial Plan Terminal Menu Setting PRI A Global Param Step Action Back out of the connection to the index number column by pressing ESC on the keyboard. Insert three more connections into the list for the BRI lines by typing the letter I three times.

  • Page 139: Figure 10-6. Completed Network Map

    Chapter 10. Dial Plan Terminal Menu Figure 10-6. Completed Network Map Setting User Term Connections Step Action Navigate to User Term. Enter connections for BRI D,E, and F in the same manner as BRI A, B, and C: use the copy ( C ) and paste ( P ) commands to enter the appropriate Out#Accept and Out#Reject numbers.

  • Page 140: Figure 10-7. Completed User Map

    Chapter 10. Dial Plan Terminal Menu Figure 10-7. Completed User Map A connection is not actually made (available) until you press Esc to move the cursor to the index number or move the cursor onto another connection line. PLUS 10-28 ATLAS 800 User Manual 61200226L1-1...

  • Page 141: Overview

    Updating Firmware Chapter 11 OVERVIEW PLUS To provide feature enhancements in the future, ATLAS 800 supports firmware updating by field personnel. Two transfer methods are available for use in updating any modules that contain Flash memory, including the PLUS ATLAS 800 system controller.

  • Page 142: Updating Firmware Using Xmodem

    • you must obtain the appropriate update file for the particular module from ADTRAN Technical Support at (888) 4ADTRAN (423-8726). • you may want to review Update Firmware on page 6-13. Instructions for Updating Firmware Using XMODEM...

  • Page 143: Figure 11-1. Update Firmware Menu Interface

    (If necessary, refer to terminal emulation software documentation for help. Also, when specifying the filename, ensure that the file transferred is the one provided by ADTRAN. Otherwise, the update will not complete successfully.) Because XMODEM data is being transferred in-band through the menu interface, the VT-100 menus of ATLAS will be inoperable from the Chain-In port.

  • Page 144: Tftp Firmware Updates

    ADTRAN Technical Support at (888) 4ADTRAN (423-8726). • you must copy the update file provided by ADTRAN to a network serv- er that supports TFTP server requests. Record both the IP address of the server and the full path location of the update file to be downloaded.

  • Page 145: Table 11-1. Tftp Upload Messages

    If an error occurred during the update process, Previous Update Status displays the appropriate error message. In this case, return to step 3 and at- tempt the update process again. If the same error occurs, contact ADTRAN Technical Support. Table 11-1. TFTP Upload Messages...

  • Page 146: Figure 11-2. Update Firmware Menu Interface

    Chapter 11. Updating Firmware Table 11-1. TFTP Upload Messages (Continued) Message Meaning Error: Illegal An unknown operation was detected by ATLAS Operation when transferring the update file from the TFTP network server. Error: User Indicates the user selected Cancel Update to Aborted abort reception of the update file from the TFTP network server.

  • Page 147: Chapter 12 Snmp Management

    SNMP Management Chapter 12 SNMP As local area network (LAN) environments became standardized over the past ten years, multivendor equipment grew with competition. It became necessary to manage various vendor equipment from a single control con- sole. Thus, Simple Network Management Protocol (SNMP) emerged as the standard for managing commercial TCP/IP networks.

  • Page 148: Snmp Traps

    Chapter 12. SNMP Management SNMP TRAPS An SNMP trap is a message sent by a network device, such as the PLUS ATLAS 800 , to report an operational anomaly or alarm condition. Trap Destination List A trap destination list contains information about sites designated to receive SNMP traps.

  • Page 149: Standard Traps

    DS1 Traps ATLAS supports RFC1406, the DS1 standard MIB, as well as the ADTRAN DS1 MIB, an extension to RFC1406. The ADTRAN DS1 group lets you send traps for DS1 Alarm Failures and Performance Threshold Crossing Alerts. The DS1 Alarm Table, defined in the ADTRAN DS1 extension MIB, contains entries that enable the status bits to send an Alarm Trap message.

  • Page 150: Ds1 Alert Traps

    Chapter 12. SNMP Management Table 12-3. DS1 SNMP Traps Alarm Severity Description Warning No alarms are present. adATLAS800NoAlarm Minor The Far end is experiencing Red Alarm adATLAS800RxYellow (a.k.a. Yellow Alarm). Warning The Near end is sending Loss Frame Indication adATLAS800TxYellow (a.k.a.

  • Page 151: Table 12-5. Total Alert Traps

    Chapter 12. SNMP Management Table 12-4. DS1 Current Alert SNMP Traps (Continued) Current Alert Severity Description Major The current interval is unavailable. adATLAS800CurrentUAS Warning The current interval path code violations have been adATLAS800CurrentCSS exceeded. Warning The current interval line errored second threshold has adATLAS800CurrentLES been exceeded.
  • Page 152 Chapter 12. SNMP Management Table 12-5. Total Alert Traps Total Alert Severity Description Warning The total interval line errored second threshold has been adATLAS800TotalLES exceeded. Warning The total interval line code violation threshold has been adATLAS800TotalLCV exceeded. When one of the Total Alert thresholds is exceeded, the corresponding event bit is set to 1 in the adDS1TotalAlert variable in the DS1 alert table.

  • Page 153: Chapter 13 Adtran Utilities

    ADTRAN Utilities Chapter 13 OVERVIEW ADTRAN delivers several PC software utilities along with the PLUS ATLAS 800 . These utilities are located on the three diskettes that came with your shipment. They also include MIB files (located in the MIB directory).

  • Page 154: Syslog Gui

    Chapter 13. ADTRAN Utilities SysLog GUI Figure 13-1 on page 13-2 shows the SysLog Host GUI. The conventional Menu Bar is described below beginning on page 13-3 (see also Figure 13-2). Other features are described here. Figure 13-1. ATLAS SysLog Host GUI...

  • Page 155: Menu Bar

    Chapter 13. ADTRAN Utilities Menu Bar The SysLog Menu Bar provides common functions. The Menu Tree shown in Figure 13-2 shows the structure. Enable File Disable Exit Set Buffer Size Limit Display Font Set Display Font Font Style Clear Display...

  • Page 156: Log Files

    Chapter 13. ADTRAN Utilities LOG FILES > Erases log files, defines Red events, sets priorities and action to be taken when an event occurs, and clears Red events. (See Define RED Events on page 13-4.) » Erase Log Files The SysLog utility, by default, stores all messages of a certain priority in a specified local log file or facility.

  • Page 157: Figure 13-3. Telnet Menu Tree

    Chapter 13. ADTRAN Utilities The Telnet menus include Session , Edit , Options , Capture , and Help (see the menu tree in Figure 13-3 on page 13-5). Host Name Connect Port Session Disconnect Edit Entry Transfer Cfg Add New...
  • Page 158 Chapter 13. ADTRAN Utilities SESSION > Click on Session to open the Telnet session. MENU » Connect Opens dialog box for setting Host Name and Port parameters for a Telnet session. Also lets you Edit Entry , Add New entry, and Delete stored entries.
  • Page 159 This option is helpful when debugging. HELP MENU > Provides on-line help for using the ADTRAN Utilities. » Contents Opens the on-line help. » IP Status Displays the local port address and the status of the connection.

  • Page 160: Figure 13-4. Vt-100 Menu Tree

    Chapter 13. ADTRAN Utilities VT-100 UTILITY Use the VT-100 to configure an ATLAS 800 which is directly connected to a PC. The VT-100 display is almost identical to the Telnet display. For a detailed description of how to work with the Telnet program, refer to Navigating the Terminal Menu on page 5-1, and for a detailed description of the VT-100 interface, see VT-100 Utility on page 13-8.
  • Page 161 Chapter 13. ADTRAN Utilities » Disconnect Closes a specified serial port at the end of a VT-100 session. » File Transfer Uploads and downloads files to and from an ATLAS. »» XMODEM CRC Selects the XMODEM file transfer protocol. »» ASCII Cfg Files Selects ASCII transfer mode.

  • Page 162: Figure 13-5. Tftp Server Interface Menu Tree

    Chapter 13. ADTRAN Utilities HELP MENU > Provides on-line help and information about the version number. » Contents Opens on-line help. » About Displays version and owner information. TFTP SERVER The TFTP Server utility transfers ATLAS 800 configuration files to and from a TFTP server.

  • Page 163: Disable

    Chapter 13. ADTRAN Utilities Figure 13-6. TFTP Server Interface Only one configuration transfer session (upload or download) may be active at a time. The TCP/IP parameters are not saved or overwritten as part of an ATLAS 800 unit’s transferred configuration to allow sending identical con- figurations to multiple units.

  • Page 164: Help

    Saving the Current Configuration to a TFTP Server Before trying to save a configuration, ensure that the TFTP server is running. If you are using the ADTRAN TFTP Server program, the server automatical- ly enables when you start the program. Also, please note the following: •...

  • Page 165: Successful Transfer

    . The file is now present on the TFTP serv- Idle er. (For the ADTRAN TFTP Server, it is stored in the installation directory or the directory you specified.) TFTP is not secure. No passwords are required for client access.
  • Page 166 Select the System Utility menu, then the Config Transfer menu. Set the TFTP Server IP Address to the IP address of the machine running the TFTP server program. (If you are using the ADTRAN TFTP server, the IP address displays in the Status field.) Change the TFTP Server filename to the filename of a previously saved configuration you wish to load.
  • Page 167 System Event Logging Appendix A This section describes the entries that may be logged by the system event log. Of particular importance is the log event’s Category – this is the mini- mum severity level that must be set in order that the event be logged. Use caution when changing Categories from their default levels.

  • Page 168: Appendix A System Event Logging

    Appendix A. System Event Logging Table A-1. Source: System Event Category Console Log String Front Panel Display String System Cold Start Normal Cold Start COLD START Generated 5 seconds after the completion of system initialization. SNMP Authentication Failure Info SNMP Authentication AUTHEN FAIL Generated if the ATLAS receives Failure...

  • Page 169: Table A-2. Source: Switchboard

    Appendix A. System Event Logging Table A-2. Source: Switchboard Event Category Console Log String Front Panel Display Call rejected Warning <number> rejected: No such number in dial plan No such number Call rejected Normal <number> rejected: Number is on outgoing reject list Outgoing reject list Call successfully routed Normal...
  • Page 170 Appendix A. System Event Logging Table A-3. Source: Nx 56/64 Event Category Console Log String Front Panel Display String Clock Slip Alarm Active Major Nx 56/64 Clock Slip Alarm Nx CLK SLIP -A Active Clock Slip Alarm Cleared Major Nx 56/64 Clock Slip Alarm Nx CLK SLIP -I Cleared Pll Alarm Active...

  • Page 171: Table A-4. Source Time

    Appendix A. System Event Logging Table A-4. Source Time Event Category Console Log String Front Panel Display String Red Alarm Set Major T1 Red Alarm Active T1 RED ALRM -A Red Alarm Cleared Major T1 Red Alarm Cleared T1 RED ALRM -I Yellow Alarm Set Major T1 Yellow Alarm Active...

  • Page 172: Table A-5. Source: Ethernet

    Appendix A. System Event Logging Table A-4. Source Time (Continued) Event Category Console Log String Front Panel Display String Current T1 Controlled Slip Warning T1 Curr CSS Thrs T1 CUR CSS Seconds Threshold Exceeded Exceeded THRS Current T1 Path Code Warning T1 Curr PCV Thrs T1 CUR PCV...

  • Page 173: Table A-6. Source: Isdn

    Appendix A. System Event Logging Table A-6. Source: ISDN Event Category Console Log String Front Panel Display String No BRI resources Critical BRI configuration failed: No NO MORE ISDN AVL available ISDN resources are available No PRI resources Critical PRI configuration failed: No NO MORE ISDN AVL available ISDN resources are...
  • Page 174 Appendix A. System Event Logging Table A-6. Source: ISDN (Continued) Event Category Console Log String Front Panel Display String PRI CPE configuration Normal Configured PRI as CPE CONFIG PRI CPE successful No B channels for call Normal No outgoing B channel available for call to <number>...
  • Page 175 Appendix A. System Event Logging Table A-6. Source: ISDN (Continued) Event Category Console Log String Front Panel Display String Call received Information Call to ATLAS: <called number> received Incoming call refused Information Incoming call to <called number> refused Incoming call accepted Information Incoming call to <called number>...

  • Page 176: Table A-7. Isdn Cause Codes

    Appendix A. System Event Logging Table A-7. ISDN Cause Codes Cause Code Message Code Category Information UNASSIGNED_NUMBER Information NO_ROUTE Information CHANNEL_UNACCEPTABLE Information NORMAL_CLEARING Information USER_BUSY Information NO_USER_RESPONDING Information CALL_REJECTED Information NUMBER_CHANGED Information DEST_OUT_OF_ORDER Information INVALID_NUMBER_FORMAT Information FACILITY_REJECTED Information RESP_TO_STAT_ENQ Information UNSPECIFIED_CAUSE Warning NO_CIRCUIT_AVAILABLE...
  • Page 177 Appendix A. System Event Logging Table A-7. ISDN Cause Codes (Continued) Cause Code Message Code Category Major INCOMPATIBLE_DEST Major INVALID_MSG_UNSPEC Major MANDATORY_IE_MISSING Major NONEXISTENT_MSG Major WRONG_MESSAGE Major BAD_INFO_ELEM Major INVALID_ELEM_CONTENTS Major WRONG_MSG_FOR_STATE Major TIMER_EXPIRY Major MANDATORY_IE_LEN_ERR Major PROTOCOL_ERROR Major INTERWORKING_UNSPEC Cause Code IEs that are non-Q.931 (Coding Standard field is not 0) are logged with the following format: <message>...

  • Page 178: Table A-8. Cause Code Log Entries

    Appendix A. System Event Logging Each Cause Code IE log entry will end with a location designation. These designations are shown below: Table A-8. Cause Code Log Entries Code Location User Private network serving the local user Public network serving the local user Transit network Public network serving the remote user...

  • Page 179: Table A-11. Source: Isdn Information Elements

    Appendix A. System Event Logging Table A-11. Source: ISDN Information Elements Event Category Console Log Front Panel String Display String ISDN Information Elements. Provides a Information <message hex dump of the ISDN IE sent with a call contents> control message PLUS 61200226L1-1 ATLAS 800...
  • Page 180 Appendix A. System Event Logging PLUS A-14 ATLAS 800 User Manual 61200226L1-1...

  • Page 181: Appendix B Troubleshooting

    Troubleshooting Appendix B Power-up Self Test Fails Modules seated improperly, module failure Remove all modules and cycle power to the unit. If self test still fails, call Technical Support and report the results. If the self test now passes, re-in- sert modules one at a time, running the self test after installing each mod- ule.
  • Page 182 Appendix B. Troubleshooting Cannot pass data from T1 interface to V.35 port Misconfiguration, improper cabling • Verify that the T1 signal is being received. If not, check that the cabling is correct. • Verify that the T1 is being received without errors. If not, double-check that framing and coding are set properly.
  • Page 183 Appendix B. Troubleshooting Cannot establish Telnet session with ATLAS Max Telnet sessions set to 0, IP address of ATLAS does not match remote host IP address • Verify that the ethernet connection is in place, check IP addresses pro- grammed in ATLAS and in the Telnet client, verify that session time- out value is not set too low.
  • Page 184 Appendix B. Troubleshooting PLUS ATLAS 800 User Manual 61200226L1-1...

  • Page 185: Appendix C Warranty And Technical Support Information

    Support Information WARRANTY AND CUSTOMER SERVICE ADTRAN will replace or repair this product within five years from the date of shipment if the product does not meet its published specifications or if it fails while in service. For detailed warranty, repair, and return information refer to the ADTRAN Equipment Warranty and Repair and Return Policy Procedure.
  • Page 186 Appendix C. Warranty and Technical Support Information Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Customer and Product Service (CAPS) de- partment to issue an RMA number. For information regarding equipment...

  • Page 187: Appendix D Acronyms And Abbreviations

    Acronyms and Abbreviations Appendix D alternate mark inversion automatic number identification B8ZS bipolar eight zero substitution Basic Rate ISDN bits per second customer premise equipment channel service unit Clear to send DACS Digital Access Cross-Connect System data communications equipment DNIS dialed number identification service digital service, level 0 (64 kbps) data service unit...
  • Page 188 Appendix D. Acronyms and Abbreviations SNMP simple network management protocol robbed bit signaling TCP/IP Transmission Control Protocol/Internet Protocol time division multiplexing TFTP Trivial File Transfer Protocol terminal service unit wide area network PLUS ATLAS 800 User Manual 61200226L1-1...

  • Page 189: Appendix E Glossary

    Glossary Appendix E 10BaseT Ethernet connection The ATLAS 800 RJ-48C port that provides Ethernet LAN connection for TFTP, SNMP, and Telnet. alternate mark inversion. A Layer 1 line code used in a T1 carrier. Zeros are transmitted as zero volts, and ones are transmitted as pulses that alternate polarity.
  • Page 190 Appendix E. Glossary byte Eight bits of information composed of zeros or ones, one of which may include a parity bit. Basic Rate ISDN. An ISDN service that offers two bearer (B) channels. One channel (64 kbps) is used for data transfer and as a data-link. The second channel (16 kbps) is used for signaling and control information.
  • Page 191 Appendix E. Glossary Digital signal (or service) having a transmission rate of 64 kbps intended to carry one voice channel (a phone call). Also called a fractional T1 because it bridges the gap between 56-kbps direct dial service (DDS) and a full T1 implementation (24 channels). data service unit.
  • Page 192 Appendix E. Glossary local area network. Group of computers and peripheral devices connected by a communications chan- nel, limited by distance. liquid crystal display. Alphanumeric characters that appear in a display area as a result of light reflect- ing off a special crystalline substance. leased line A telecommunication facility or link reserved for the exclusive use of one customer.
  • Page 193 Appendix E. Glossary option modules Any optional, hot-swappable module that can be added to the ATLAS 800 system for a variety of applications. See also overbooking ATLAS 800 feature that reduces telecommunications expenses by allowing you to over-subscribe switched bandwidth for situations where simultaneous access to the network by every subscriber is not required.
  • Page 194 A direct line between two telephone switching centers. terminal service unit. T-Watch PRO The ADTRAN Microsoft Widows-based management software program designed to control TSU units from a remote PC. It also provides limited control over the configuration of the ATLAS 800 using a graphical user interface.

  • Page 195: Index

    ADLP address 6-7 reject 10-7 ADTRAN authenticate trap transmission 6-9 utilities 13-1 auto daylight savings 6-10 ADTRAN data link layer protocol address 6-7 auto repeat 13-7, 13-9 alarm auto TX yellow alarm 7-6 blue 7-4 automatic red 7-4 routeback rejection 10-9...
  • Page 196 9-6 IP address 6-8 delay 9-6 module slots 7-2 from 9-5 subnet mask 6-8 line status 9-6 configuring ATLAS 800 PLUS 6-1 man 9-5 configuring Syslog 6-10 test 9-7 connect Circuit Status Menu 9-5 Telnet menu 13-6 circuit status menu 9-5...
  • Page 197 Index connection accept 10-4, 10-7 reject 10-5, 10-7 activate 8-2 data field, described 4-5 control in / chain in 2-4 data tables 6-5, 6-6 create/edit 8-2 configuring 6-6 current 8-2 date 4-9 dedicated 7-6 current 6-10 ethernet 10BaseT 2-7 restart schedule 6-15 from 8-3 restart system 6-14 LAN 2-7...
  • Page 198 Index complete 10-27 wink 10-12, 10-16 creating 10-21 edit implementing 10-25 dedicated map 8-2 network terminations 10-3 entry (Telnet utility) 13-6 plan 10-23 editing front panel data fields 4-5 provision network 10-23 empty module slot 7-3 remote access setup 10-22 enable sample network terminations 10-24 TFTP 13-11...
  • Page 199 Index TFTP server 6-14, 6-16 module status LEDs 4-2 firmware navigating 4-5 begin update 6-15 navigation example 3-2 revision 6-3 numeric keypad 4-2 update 6-13 online status 4-2 begin 6-15 operation 4-1 module slot 6-14 operation keys 4-4 restart schedule 6-14 return to main menu 4-4 TFTP 6-14, 11-1, 11-4 selecting menus 4-5...
  • Page 200 6-11 password 6-11 Installation 2-1 line build out 7-6 installed memory 6-3 line code 7-6 installing line code violaions 7-5 ATLAS 800 PLUS 2-1 line errored seconds 7-5 modules 2-8 line status 9-6 interface active 9-6 configuration inactive 9-6...
  • Page 201 Index installed 6-3 online 7-3 menu status 7-3 alarm 4-11 test 7-2 configuration 4-7 test pattern 7-7 module 7-2 modules menu 7-1 modules 6-20 MON 2-3, 2-7 path 5-1 MON test jack 2-7 session 13-6 Monitor 2-3 status 4-7 monitor 2-7 submenu 7-3 most significant digits (MSD) 10-10, 10-13, 10-14, system status 6-3...
  • Page 202 4-1 test pattern (modules) 7-7 terminal menu 5-1, 10-1 pattern clear 7-7 VT 100 3-4 PC management 3-5 operating ATLAS 800 PLUS 3-1 performance operation 3-1 15 minutes 7-5 operation keys 4-4 24 hour 7-5 operation keys, described 4-4...
  • Page 203 Index dial plan 10-3 RCV 7-5 ethernet 2-7 real time clock 6-10 ethernet status 6-5 rear panel 2-3 name 7-5 reboot system 6-20 configure ethernet port 6-8 receive level 7-4 speed 6-9 red alarm 7-4 port name 7-5 red CSU LED 4-3 port type red module status LED 4-3 configure chain port 6-9...
  • Page 204 Index Rx frames 6-5 signaling dial plan 10-3 status 7-4 S0 system signaling conversion config menu 4-7 description 1-3 status menu 4-7 signaling method 10-12, 10-16 S1-S8 slot 6-4 config menu 4-9 dial plan 10-3 status menu 4-7 update firmware 6-14 save slot/port configuration file 6-17...
  • Page 205 Index status menu utility menu 6-13 chain port status 4-7 system LED 4-3 ethernet status 4-7 S1-S8 4-7 stopping current activity 4-2 T1 bandwidth management storing description 1-4 configuration on TFTP server 13-12 T1/PRI interface ports 7-1 Strip MSD 10-19, 10-20 TANULL Timer 6-12 strip MSD 10-10, 10-13, 10-14, 10-17 TCID Timer 6-13...
  • Page 206 Index Test Call 9-4 number 10-13 test jack 2-7 trunk conditioning 8-4 MON 2-7 trunk usage 6-6 Test Now 9-7 T-Watch PRO 3-5 test pattern 7-7 error inject 7-7 ethernet status 4-7 test status 4-2 Tx frames 6-5 testing Tx PRMs 7-6 power up 2-8 Tx yellow alarm TFTP...
  • Page 207 Index utility menu 4-9 view log 6-4 warranty C-1 window video conferencing LCD 4-1 setup with dial plan 10-22 writing view configuration to TFTP server 13-12 event log 6-10 selftest log 6-17 view error log 6-4 XMODEM view history 4-12 update firmware 6-13, 6-14, 11-1 VT 100 delivered utility 13-8...
  • Page 208 Index PLUS Index-14 ATLAS 800 User Manual 61200226L1-1...
  • Page 209 (888) 4ADTRAN Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Custom and Product Service (CAPS) department to issue an RMA number. For information regarding equipment currently in house or possible fees associ-...

This manual is also suitable for:

1200226l11200228l1

Table of Contents
