Quick Start
Guide

Overview

f
WARNING!
Read all warnings, cautions, notes and installation instructions before installing or servicing this equipment.
The 854-(v)6 is a carrier-class, dual-band, Wi-Fi 6 2.5G Router designed to deliver top-end Wi-Fi 6 performance, Gigabit throughput, and advanced
service delivery capabilities.

Features

The features of the 854-(v)6 include the following:
■ Combo WAN Uplink (one at a time)
SFP WAN interface
♦ 2.5G Ethernet WAN interface
■ 4x Gigabit Ethernet LAN interfaces (RJ-45)
■ 2x Voice (RJ-11) interfaces (854-v6 only)
This quick start describes how to install and connect to the device.
"Installing the 854-(v)6 2.5G Router"
"Understanding the Status LEDs"
"Logging Into the 854-(v)6"
"Product Specifications"
"Safety and Regulatory"
Multi-function
Status LED
f
WARNING!
WARNING indicates a hazard which, if
not avoided, could result in death, injury
or serious property damage.
854-(v)6 Service Delivery Gateway
Wi-Fi 6 2.5G Router
October 2022
6SDG8546V6-13A
on page 2
on page 3
on page 5
on page 6
on page 6
f
CAUTION indicates a hazard which, if not
avoided, could result in service interruption,
damage to the equipment, or minor property
damage.
P/N: 17600028F1, 17600028F2, 17600028F3, 17600028F4
USB 3.0 Host Port
WPS/Reset Reset
4x LAN Ports
2.5G WAN Port
12VDC Power
Input
SFP WAN Interface
Figure 1. 854-(v)6 Router
CAUTION!
Status LEDs
2x Voice Interfaces
g
NOTE
NOTES inform the user of additional, but
important, information or features.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 854-(v)6 and is the answer not in the manual?

Questions and answers

Edwin K Pert
February 26, 2025

How do i find the password

1 comments:
Mr. Anderson
February 26, 2025

The default password for the ADTRAN 854-(v)6 is unique and can be found on the label located at the underside of the hardware. If the password has been changed and forgotten, you can reset the device to factory defaults and follow the setup instructions.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for ADTRAN 854-(v)6

  • Page 1 WARNING! Read all warnings, cautions, notes and installation instructions before installing or servicing this equipment. The 854-(v)6 is a carrier-class, dual-band, Wi-Fi 6 2.5G Router designed to deliver top-end Wi-Fi 6 performance, Gigabit throughput, and advanced service delivery capabilities. Features The features of the 854-(v)6 include the following: ■...
  • Page 2 No special tools are required for installing the 854-(v)6. Mounting Options There are two options to install the 854-(v)6: desktop and wall mount. Be sure to route and secure the cables in a manner that will prevent damage. These options are described below.
  • Page 3 Resetting the Device A reset button is available if the 854-(v)6 needs to be rebooted or restored to factory defaults. To reboot the 854-(v)6, press the Reset button on the back panel of the device for less than 5 seconds. To reset the device to factory defaults, press the Reset button for 5 seconds or more.
  • Page 4 Claimed device (by another account) Rapid Blinking TFTP/recovery blink Back Panel Status LEDs There are six LEDs located on the back panel of the 854-(v)6 as shown in Figure Figure 2. Status LEDs Fiber Status LED When SFP fiber connection is active, the Fiber status LED will indicate the status of Fiber connectivity.
  • Page 5 The SDG product line can ship with two possible firmware options: PlumeOS and SmartOS. Quick setup instructions of Wi-Fi and connection to the Internet for your 854-(v)6 will vary based on which OS is installed on the device. Confirm whether your 854-(v)6 is deployed with SmartOS firmware or PlumeOS firmware, then choose accordingly from the following options.
  • Page 6 Electrical ■ Power is provided by a 12V DC power adapter that is included with the 854-(v)6. The power adapter operates from a power source of 100 to 240V AC, 50 - 60 Hz. The nominal output is 12V DC ±5% with a minimum current rating of 3.0 Amps. For US and Canadian applications, a UL Listed limited power source (LPS) is supplied and required for use.
  • Page 7 Canadian Department of Communications Radio Interference Regulations This digital apparatus (Wi-Fi 6 2.5G Router Model 854-(v)6) does not exceed the Class B limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 8 For Adtran training inquiries, visit: https://adtran.com/training https://adtran.com/sdg-info Adtran CUSTOMER CARE: Warranty: Adtran will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can From within the U.S. 1.888.423.8726 be found online at https://adtran.com/warranty-terms.

This manual is also suitable for:

17600028f117600028f217600028f317600028f4
